Overview of the AXIS F4108 sensor unit
- Captures video in 4K resolution at up to 25 fps
- 4.3mm F1.8 lens for horizontal viewing field of 107°
- Forensic WDR balances scenes with difficult lighting
- Dome design for wide angle coverage and flexible mounting
- Compatible with F9114-R Mk II and F9111-R Mk II main units
Please note: this sensor unit is designed for use with the Axis F9114-R Mk II and Axis F9111-R Mk II main units and is not a standalone network camera.
For use with Axis F91 main units, this modular dome sensor enables discreet installation suitable for indoor use. Capture video in 4K video resolution for crisp and clear images, whilst support for Lightfinder and Forensic WDR ensures enhanced clarity in difficult lighting. It offers a wide horizontal viewing angle of 107° for extra coverage, even when installed in confined areas.
Installation
This dome sensor can be mounted to ceilings and walls straight out of the box with the included mounting plate. Furthermore, the sensor can be situated up to 30m away from the main unit, where configuration can take place to allow video and analytics management for each connected sensor.
Please note: the required cables for this sensor to connect to the main unit are sold separately.
Example Use Cases
- ATMs and cash-handling areas such as bank tellers and cashier desks
- Door-entry systems, ingress and egress points, fire escapes, vending machines
Accessories
Included:
- Sensor
- Installation guide
Key technical features of the AXIS F4108 indoor compact indoor sensor unit
Camera |
|
| Environment: | indoor |
| Type: | Modular sensor for use with AXIS F91 main units |
| Sensor: | 1/2.9” progressive scan RGB CMOS
Pixel size 1.4 µm |
| Lens: | 4.3 mm, F1.8
Horizontal field of view: 107° Vertical field of view: 54° Minimum focus distance: 2.0 m (6.6 ft) Fixed iris |
| Camera adjustment: | Pan -92 to +260°, tilt 0 to 62°, roll 0 to 90° |
| Power: | Typical 0.9 W |
Imaging |
|
| Resolution: | Maximum 3840x2160 |
| Frame rate: | See AXIS F91 main units datasheet |
| WDR | Forensic WDR: Up to 120 dB depending on scene |
General |
|
| Connectors: | SMA connector |
| Required hardware: | AXIS F91 Main Unit
Requires one of the following cables: AXIS TU6004-E Cable AXIS TU6005 Plenum Cable AXIS TU6007-E Cable |
| Dimensions: | For the overall product dimensions, see the dimension drawing in the datasheet. |
| Weight: | 90 g (0.2 lb) |
| Casing: | Aluminum and plastic casing |
| Operating temperatures: | Temperature: -20 °C to 50 °C (-4 °F to 122 °F)
Humidity: 10–85% RH (non-condensing) |
| Warranty: | 5-year |
