Overview of the AXIS Camera Station S1228 AI-Optimised Server
- Out-of-the-box 1U rack mounted recording server optimised for rapid video retrieval
- Preloaded with 28 AXIS Camera Station Pro licences
- Includes 1 x 12TB HDD internal storage with RAID 0,1 support
- One empty hard drive bay for storage expansion
- Expand up to 36 channels with additional ACS Pro licences
Designed for rapid evidence retrieval in fast-moving environments, the AXIS S1228 rack recording server features a high-performance CPU, GPU, dual SSDs, and high transmission throughput. It’s optimised for Smart Search and free-text queries, enabling fast indexing and efficient video retrieval.
Preloaded with AXIS Camera Station Pro software and supplied with 28 licenses, this server allows you to get up and running quickly. It is optimised to handle up to 300 Mbit/s recording throughput for smooth and detailed video across your network, capable of supporting up to 32 video channels in total. 1 x 12TB HDD storage is included, expandable with 1 additional hard drive slot to suit your storage needs up to 24TB total. The device supports multiple RAID configurations (0,1) for reliable system redundancy. It features 3 x USB ports for connecting external devices such as the AXIS TU9001 Control Board for PTZ control.
The AXIS S1228 recorder is designed with future growth in mind, letting you scale up your system even further with additional AXIS Camera Station NVR licences, and integrating AXIS S3008 Recorders for cost-efficient system expansion. Installation is made simple with the intuitive AXIS Recorder Toolbox and setup wizard.
Video Management
Access live and recorded high-definition video, export footage and manage alarms with AXIS Camera Station VMS software. The device comes with the latest version preinstalled, so you can get started straight away. The AXIS Recorder Toolbox features an installation wizard, toolbox and supporting materials to ensure trouble-free setup, whilst also enabling access to the latest software updates and additional features provided by AXIS free of charge, such as access via AXIS My Systems.
Video Analytics
As the device runs AXIS Camera Station Pro software, it fully supports the complete range of AXIS analytics technologies, such as AXIS Object Analytics for detecting and classifying humans and vehicles. Receive alerts for events detected by supported AXIS cameras, enabling rapid response to potential incidents as well as developing valuable insights into business performance.
Built using powerful components, this server is optimised for AI-based video retrieval applications such as Smart Search 2. This advanced forensic search feature allows you to easily find objects of interest captured in recordings by setting several filters such as vehicle type and clothing colour to rapidly retrieve specific footage.
Accessories
Included:
- Recorder
- Dell Ready Rails 1U Static Rails
- C13 to C14 power cord for rack PDU (Wall plug power cords are not included)
Optional:
- WD Purple Surveillance Grade Hard Drives
- AXIS TU9001 control board
- AXIS S3008 Mk II Network Video Recorder
- AXIS S3016 Rack Recorder/NVR
- AXIS Camera Station S9301 Workstation
- AXIS Camera Station S9302 Workstation
Key technical features of the AXIS Camera Station S1228 AI-Optimised Server
Licences |
|
| Licences: | 28 AXIS Camera Station Pro Core Device NVR licenses included and tied to the hardware. Can be upgraded to 32 with additional licenses (sold separately). |
| System scalability: | Qualified for 64 doors and 32 video channels with a
total recording bitrate up to 300 Mbit/s.
Check AXIS Site Designer for storage estimates. Can be scaled with more devices when using AXIS S30 Recorder Series. Qualified for up to 1,000 doors with access control only. Tested with: 20 live view clients 2 clients performing heavy playback or scrubbing operations |
| Capacity: | Smart search classification capacity:
1080p: 3000/min 720p: 5500/min Approximate capacity for the entire system; actual performance may vary. Requires AXIS Camera Station Pro 6.8 or higher |
Hardware |
|
| Form factor: | 1U rack mounted |
| Processor: | Intel® Xeon® E processor |
| Memory: | 2 x 16 GB |
| Storage: | Cold swappable Enterprise Class SATA HDD, 7200 rpm.
Total HDD slots: 2 Free HDD slot: 1 Out-of-the-box storage: 12 TB (1x 12 TB) 960GB SSD (Smart search database |
| RAID: | Factory RAID level: Not configured
Supported RAID levels: 0, 1 |
| Graphics card: | Nvidia® A series |
| Power: | 450 W Platinum (100–240 V AC), 6.5–3.5 A, 50/60 Hz |
| Power consumption: | Typical: 130 W (443.6 BTU/h)
Maximum: 210 W (716.6 BTU/h) |
| Connectors: | Front side:
1x USB 2.0 1x iDRAC direct port Rear side: 1x USB 2.0 1x USB 3.2 1x VGA1 4x Mini DisplayPort™1 1x Serial port 1x iDRAC dedicated Ethernet port 2x RJ45 1 Gbps |
Video |
|
| Video streaming: | Not intended for local viewing of video.
Recommended to use AXIS workstations |
General |
|
| Operating system: | Microsoft® Windows® 11 IoT Enterprise LTSC 2024
Built-in operating system recovery: yes Operating system drive: 480 GB SSD |
| Remote server management: | iDRAC 9 basic license |
| Operating conditions: | 10 °C to 35 °C (50 °F to 95 °F)
Humidity 8–80% RH (non-condensing) |
| Dimensions: | 496.74 x 482 x 42.8 mm (19.56 x 19 x 1.68), 1U chassis
Rail sizing: Type: static, square hole Minimum rail depth2 : 622 mm (24.49 in) Product installation depth3 : 461.14 mm (18.16 in) Rail adjustability range4 : 608–879 mm (23.94–34.61 in) |
| Weight: | 8.5 kg (18.7 lb)) |
| Included accessories: | Dell Ready Rails 1U Static Rails, C13 to C14 power cord for rack PDU (Wall plug power cords are not included) |
| Optional accessories: | AXIS workstations
Surveillance grade hard disc drives |
| Services: | Next Business Day Onsite Support
Keep Your Hard Drive |
| Hardware warranty: | Recorder and hard drive: 5-year warranty |
