Overview of the AXIS I8307-VE network video intercom door reader
- High-quality two-way video and audio for visitor identification and verification
- 4K video network video intercom with AXIS Object Analytics
- Works seamlessly with AXIS door controllers and credentials
- 7" customisable touch screen with integrated RFID reader and keypad
- Outdoor-ready with IP66 and IK08 rating for effective weather and vandalism protection
Offering two-way video and audio, this network video intercom delivers a high-quality solution for access control, visitor identification, and entry management. It features a 4K resolution camera with Forensic WDR to ensure clear, detailed images even in challenging lighting conditions such as shaded entrances. Visitors can gain access using the 7" touch screen with integrated RFID reader and keypad. The screen can display live video and images such as maps showing directions. It supports contactless entry via cards or key fobs using 13.56MHz credential technology, as well as use of the AXIS Mobile Credential when AXIS Barcode Reader is installed on the unit. Designed to work seamlessly with AXIS door controllers and managed credentials, it delivers a complete and secure access control setup. SIP and VAPIX support allows for easy integration to internal phone and video systems. A built-in PIR sensor detects nearby motion, activating the unit without the need for continuous recording.
The device offers flexible installation and can be mounted directly to walls out of the box, or to poles with the Axis T91B47 Pole Mount.
Video Analytics
AXIS Object Analytics (AOA) enhances access control by detecting and classifying people and vehicles at entry points, helping to identify visitors and manage movement in real time. Powered by the ARTPEC-8 chip with deep learning, it filters out irrelevant motion to reduce false alarms. Colour-coded bounding boxes highlight detected objects, and up to 10 virtual rules such as line crossing or zone entry can be configured for targeted monitoring. Image Health Analytics alerts you to issues affecting the camera’s view, such as obstructions or tampering.
Recording and Video Management
See below for available recording and video management options for this device:
- Record directly to on-board microSD Card (not included)
- AXIS Camera Station Software
- AXIS Camera Station NVRs
- Milestone XProtect video management software
- Milestone Arcules VSaaS
- Morphean Cloud CCTV
Access Control Management
Available access control management solutions for this device:
- Axis Camera Station Secure Entry (included with Axis Camera Station software)
- Milestone XProtect - Access add-on application
- Morphean Access Control - 1 year door licence
Included Accessories
- Intercom
- Installation guide
- Terminal block connector kit
- Grounding screw
- Connector guard
- Cable gaskets
- Owner authentication key
Key technical features of the AXIS I8307-VE network video intercom door reader
Camera |
|
| Image sensor: | 1/1.8” progressive scan RGB CMOS
Pixel size 2 µm |
| Lens: | 2.2 mm, F1.8
Horizontal field of view: 150° Vertical field of view: 112° Fixed focus, fixed iris |
| Minimum illumination: | 0.04 lux at 50 IRE, F1.8 |
Video |
|
| Resolution: | 16:9: 3840x2160 to 160x90
16:10: 2560x1600 to 160x100 4:3: 2880x2160 to 160x120 |
| Frame rate: | With Forensic WDR: Up to 25/30 fps (50/60 Hz) in all
resolutions
WDR off: Up to 50/60 fps (50/60 Hz) in all resolutions |
| WDR: | Forensic WDR: Up to 120 dB depending on scene |
Audio |
|
| Audio features: | Echo cancellation, noise reduction, beamforming |
| Audio streaming: | Two-way (full duplex) |
| Audio input: | Unbalanced line input, 2x built-in microphones (can be disabled) |
| Audio output: | Line output, built-in speaker
T-coil Max 85 dBSPL (at 1 m / 39 in) |
Reader |
|
| Lock integration: | Integration with AXIS A9801 Security Relay: 350 mA at 12 V DC
Integration with Axis network door controllers: maximum current/voltage: 0.7 A at 30 V |
| Entry authentication: | Card, tag, PIN, door code
Integrated entry list with up to 50 credentials) |
| Alarm status indication: | User feedback for access granted, access denied, keypad, armed, disarmed. |
| Reader technology: | Generic 13.56 MHz (MIFARE Classic®, MIFARE Plus® (level 1), MIFARE DESFire® EV2 and EV3, HID® iCLASS®, HID® iCLASS SE®, HID® Seos®). Proximity 125 kHz (HID® Prox, EM-42xx, ISOProx II) |
| Network protocols: | RS485 (OSDP), Wiegand, VAPIX® reader interface |
Video Management |
|
| On-camera recording: | Support for microSD/microSDHC/microSDXC card Recording to network-attached storage (NAS) |
| Network video recorders: | Axis NVRs, Milestone Husky NVRs, ONVIF support for 3rd party NVRs |
| Video Management Software: | Axis Camera Station, Milestone XProtect, ONVIF support for 3rd party VMS |
| Cloud: | Milestone Arcules VSaaS, |
Security |
|
| Edge security: | Edge security
Software: Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, Axis Cryptographic Module (FIPS 140-2 level 1) Hardware: Axis Edge Vault cybersecurity platform Secure keystore: secure element (CC EAL 6+, FIPS 140-3 Level 3), system-on-chip security (TEE) Axis device ID, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit) |
| Nework security: | IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)3 , HTTPS/HSTS3 , TLS v1.2/v1.33 , Network Time Security (NTS) |
Analytics |
|
| Applications: | Included
AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection Support for AXIS Camera Application Platform enabling installation of third-party applications |
| AXIS Object Analytics: | Object classes: humans, vehicles (types: cars, buses,
trucks, bikes, other)
Scenarios: line crossing, object in area, time in area, crossline counting, occupancy in area, motion in area, motion line crossing Up to 10 scenarios Other features: triggered objects visualized with trajectories, color-coded bounding boxes and tables Polygon include/exclude areas Perspective configuration ONVIF Motion Alarm event |
General |
|
| Display: | 7-inch capacitive touch display
Resolution: 800x480 Interactive 7” touch display with illuminated RFID symbol and audible feedback |
| Casing: | IP66-, NEMA 4X-rated, IK08 impact- and scratchresistant glass
Aluminium casing Colour: black NCS S 9000-N |
| Mounting: | Wall, recessed, conduit (with adapter), or pole mounting |
| Power: | Power in:
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3, or Power over Ethernet Plus (PoE+) IEEE 802.3at Type 2 Class 4, or 18–28 V DC min. 25 W Power consumption: typical 7 W, max 25 W Power out: Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3: 24 V/0.05 A or 12 V/0.1 A Power over Ethernet Plus (PoE+) IEEE 802.3at Type 2 Class 4, or 18–28 V DC: 24 V/0.3 A or 12 V/0.6 A Relay rating: 30 V, 1 A |
| Connectors: | Network: RJ45 10BASE-T/100BASE-TX PoE
I/O: 6-pin 2.5 mm terminal block for 4 alarm inputs/ outputs Audio: line in, line out, terminal block Serial communication: RS485/Wiegand, terminal block Power: DC input, terminal block 2 relays |
| PIR sensor: | Passive infrared (PIR) motion sensor |
| Operating conditions: | Temperature: -30 °C to 55 °C (-22 °F to 131 °F)
Humidity: 10–100% RH (condensing) |
| Dimensions: | For the overall product dimensions, see the dimension
drawing in the datasheet.
Effective Projected Area (EPA): 0.042 m2 (0.45 ft2) |
| Weight: | 2069 g (4.6 lb) |
| Box content: | Intercom, installation guide, terminal block connector kit, grounding screw, connector guard, cable gaskets, owner authentication key |
| Warranty: | Axis 5-year warranty |
