| 01037-001

Axis M3106-LVE Mk II outdoor mini-dome with 4MP resolution, up to 15m IR, WDR, Zipstream, edge storage, H.265 and PoE

Free delivery on mainland UK and most EU countries Check delivery charges to where you are.
Hurry! Only left

This product is discontinued, an alternative model is the Axis M3116-LVE.

Overview of the Axis M3106-LVE Mk II

This robust mini-dome by Axis delivers clear 4MP/Quad HD 1440p (4 x 720p) resolution images, complete with built-in infrared (IR) illumination for true day/night recording and a flat-faced design that supresses reflections. Its outdoor housing is vandal-resistant and adjustable to offer flexibility when mounting in external locations. Additional features include Axis Zipstream technology, H.265 compression format, edge storage and support for Power-over-Ethernet (PoE) to help simplify installation.

The unit offers improved imaging in low-light thanks to the integrated IR LED that illuminates up to 15m, and its innovative flat-faced design helps to suppress light reflections. Using Axis Corridor Format, users can vertically orientate the video stream to help maximise area coverage and reduce bandwidth when monitoring narrow scenes. In addition, support for multi-view streaming allows a maximum of 2 areas in the camera's field of view to be cropped and streamed separately for live viewing or recording.

The Axis Companion application is free to download and offers a simple video management solution for up to 16 IP cameras. Available as a PC client or mobile application for iOS and android devices, this handy software offers remote access to live views as well as playback of recordings.

Users can configure camera-based video motion detection and tampering alarms to help notify them of activity via a choice of notifications including email. These motion detection alarms can also be set to trigger MicroSD card recording when using the Axis Companion mobile app.

For simple installation, the unit can be powered using PoE and also includes a handy 3-axis mount for easy adjustment of the lens to obtain the desired view. Axis Zipstream technology lowers bandwidth and storage requirements, ensuring important details within the image are maintained within the stream, while unnecessary data can be removed

Please note: this camera does not come with a power supply, please select from the accessories tab if required.

Key features & benefits

  • Capable of delivering high quality 4MP/Quad HD 1440p resolution at 25 fps for detail-packed video footage
  • Integrated IR-cut filter provides true day/night functionality for round-the-clock surveillance
  • Robust, vandal-resistant housing provides protection in exposed locations
  • Long-life, built-in infrared LED provides up to 15m of night-vision
  • Innovative flat-faced design reduces light reflections to improve images captured in low light
  • Axis Corridor Format optimises the field of view in narrow scenes – capturing only what is essential
  • Multi-view streaming allows 2 areas of interest to be streamed at full frame rate
  • Free video management for up to 16 cameras using the Axis Companion application
  • Enhanced security monitoring with a range of camera-based video motion detection and tampering alarms
  • On-board recording to MicroSD card provides cost-effective, local storage that doubles as a data backup solution
  • PoE allows the camera to receive power and network connectivity over a single cable, reducing costs and installation time
  • Easy manual adjustment and quick set up of the lens using the handy 3-axis mount
  • Axis Zipstream technology lowers bandwidth and storage by retaining important image details and removing unnecessary data
  • H.265 compression format offers further reductions on bandwidth and storage over H.264

Compatible recording platforms

  • Axis Camera Station
  • Milestone XProtect
  • Axis Companion application (free)

Typical applications

The Axis M3106-LVE Mk II mini-dome IP camera delivers high quality 4MP resolution images round the clock. It’s ideal for users that require 24-hour surveillance in exposed areas such as car parks, schools and community centres.



  • Installation Guide
  • Windows decoder 1-user license
  • Torx L-key

Optional (select from accessories tab):

  • PoE midspan
  • MicroSD card
Back To Top

Key technical features of the Axis M3106-LVE Mk II


Environment: outdoor (IP66 and IK08 rated)
Type: fixed mini dome
Sensor: 1/3” progressive scan RGB CMOS
Lens: M12 mount, fixed iris, fixed focus, 2.4 mm, F2.2, horizontal field of view: 130°
Audio: not given
Power: Power-over-Ethernet IEEE 802.3af/802.3at Type 1 Class 3, typical: 5.1 W, max: 7.9 W
Memory: 512 MB RAM, 256 MB Flash


Resolution: (2688 x 1520) to (320 x 240)
Compression: H.264 (MPEG-4 Part 10/AVC), Main, Baseline and High Profiles, H.265 (MPEG-H Part 2/HEVC) Main Profile, Motion JPEG
Frame-rate: up to 25 fps
Bandwidth control: multiple, individually configurable streams in H.264, H.265 and Motion JPEG, controllable frame rate and bandwidth, Axis' Zipstream technology in H.264 and H.265, VBR/MBR H.264/H.265
Day/night: automatically removable infrared-cut filter
Minimum illumination: colour: 0.3 lux, b/w: 0.06 lux, 0 lux with IR illumination on, IR illumination: 15m
Digital zoom/PTZ yes
Video overlay: text and image
Imaging: compression, colour, brightness, sharpness, contrast, white balance, exposure control, backlight compensation, wide dynamic range, rotation: 0°, 90°, 180°, 270°, mirroring of images, including Corridor Format

Viewing, detection & recording

Privacy masking: yes
Number of users: not given
External alarm inputs and outputs not given
Alarm detection: AXIS Video Motion Detection 3, Active tampering alarm, support for AXIS Camera Application Platform enabling installation of AXIS Cross Line Detection and third-party applications
Alarm action: notification: email, HTTP, HTTPS and TCP and SNMP trap, video recording to edge storage, send video clip, overlay text
Pre-/post-alarm buffer: yes
On-camera recording: MicroSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included), support for recording to dedicated network-attached storage (NAS)
Recording software supported: Axis Companion Software, Axis Camera Station


Power: Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3
Network: RJ45 10BASE-T/100BASE-TX PoE, max. 7.9 W
Alarm I/O not given


Dimensions: Ø101mm x 94mm
Weight: 0.37kg
Casing: colour: white, IP66, NEMA 250 Type 4X and IK08-rated, ASA polymer casing
Warranty: 3 years
Mounting methods: ceiling, wall
Operating temperatures: -30°C to 50°C
Power consumption: max. 7.9W
Dynamic DNS: yes
Protocols supported: IPv4/v6, HTTP, HTTPSa, SSL/TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
QoS: yes
Security: password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb network access control, digest authentication, user access log
ONVIF compliant: yes, profile S
