Built for for demanding and mission-critical applications, this all-in-one bispectral PTZ camera combines dual 1080p visual lens and a 384x288 QVGA thermal lens all through one unit and a single IP address. The fixed 7mm thermal lens provides up to 55° views for wide scene coverage, with the unit’s visual lens offering HD 1080p resolution and powerful 31x optical zoom. Alongside Forensic WDR and OptimizedIR illumination up to an impressive 150m range, this camera delivers enhanced monitoring in all weather and light conditions. The highly sensitive thermal sensor enables high-accuracy detection and early warnings of moving objects, complementing the high-level detail captured by the visual lens.
The device features full 360° endless pan and ground-to-sky view for coverage of exposed areas. Robust and hard-wearing, the device is IP66 and IK10 rated for effective weather and vandalism protection, and includes a built-in wiper for maintaining visibility in wet conditions. The unit can be mounted to walls, poles and corners with additional accessories. The camera is also suitable for repainting with the included repaint template to help better suit its surroundings.
AXIS Object Analytics (AOA) delivers intelligent perimeter detection by combining thermal and visual imaging to provide highly reliable event detection in all lighting and weather conditions. AI powered analytics accurately classify people and vehicles while minimising false alarms caused by wildlife, shadows, rain, or moving vegetation. Implement up to 10 simultaneous scenarios such as virtual line crossing, intrusion zones and loitering rules, with detected objects highlighted on screen for rapid threat assessment and response. Support for AXIS Perimeter Defender enables enhanced area detection capabilities using thermal technology.
This camera also supports other Axis and third-party applications, enabling greater functionality for the camera to meet more specialist demands.
Available recording and video management options for this camera:
Camera |
|
| Environment: | outdoor |
| Type: | PTZ dome camera |
Visual Sensor |
|
| Sensor: | 1/1.2” progressive scan RGB CMOS |
| Lens: | Optical zoom: 31x
Focal length: 6.91 – 214.64 mm Horizontal field of view: 59.6 – 1.0° Vertical field of view: 36.3°– 0.5° Autofocus, P-iris |
| Resolution: | 1920x1080 (HDTV 1080p) to 640x360 |
| Frame rate: | Up to 50/60 fps (50/60 Hz) in all resolutions |
| Day/night: | Automatically removable infrared-cut filter
Removable infrared-pass filter |
| Minimum illumination: | Colour: 0.06 lux at 30 IRE, F1.36
B/W: 0.001 lux at 30 IRE, F1.36, 0 lux with IR illumination on Colour: 0.09 lux at 50 IRE, F1.36 B/W: 0.008 lux at 50 IRE, F1.36, 0 lux with IR illumination on |
| IR illumination: | OptimizedIR with power-efficient, long-life 850 nm IR
LEDs
Range of reach 150 m (492 ft) or more depending on the scene |
| Image settings: | Compression, colour, brightness, sharpness, white
balance, exposure control, exposure zones, image freeze
on PTZ, scene profiles, rotation, electronic image
stabilization (EIS), defogging, barrel distortion
correction
Contrast, local contrast, autofocus, Forensic WDR: Up to 120 dB depending on scene, 100 individual polygon privacy masks including mosaic and chameleon privacy masks |
Thermal Sensor |
|
| Sensor: | Uncooled microbolometer
384x288 pixels, pixels size: 17 μm Spectral range: 8-14 μm |
| Lens: | Athermalized
7 mm, F1.18 Horizontal field of view: 55° Vertical field of view: 41° Near focus distance: 1.2 m (3.9 ft |
| Sensitivity: | NETD <20 mK @25 °C, F1.0 |
| Resolution: | Sensor is 384x288. Image can be scaled up to 768x576. |
| Frame rate: | Up to 8.3 fps or 30 fps depending on model |
| Image settings: | Barrel distortion correction, gain, electronic image stabilization, contrast, sharpness, brightness, exposure zones, compression, dynamic text and image overlay, polygon privacy mask, thermal palettes |
Imaging |
|
| WDR: | Forensic WDR: Up to 120 dB depending on scene |
| Video streaming: | Up to 20 unique and configurable video streams1
Axis Zipstream technology in H.264, H.265, and AV1 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265/AV1 Low latency mode Video streaming indicator |
| Installation aids: | Pixel counter, remote zoom and focus, straighten image, traffic camera installation assistant |
Analytics |
|
| Applications: | Included
Visual: AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS OSDI Zone, Orientation Aid PTZ, advanced gatekeeper, autotracking 2, AXIS Image Health Analytics, AXIS Live Privacy Shield Supported AXIS Perimeter Defender Support for AXIS Camera Application Platform enabling installation of third-party applications |
| Axis Object Analytics (AOA): | Visual:
Object classes: humans, vehicles (types: cars, buses, trucks, bikes, other) Scenarios: line crossing, object in area, time in area, crossline counting, tailgating detection, PPE monitoringBETA, motion in area, motion line crossing Up to 10 scenarios Other features: triggered objects visualized with trajectories, colour-coded bounding boxes and tables Polygon include/exclude areas Perspective configuration ONVIF Motion Alarm event |
| Axis Image Health Analytics: | Visual
Detection settings: Tampering: blocked image, redirected image Image degradation: blurred image, underexposed image Other features: sensitivity, validation period |
| Axis Scene Metadata: | Visual:
Object classes: humans, faces, vehicles (types: cars, buses, trucks, bikes), license plates Object attributes: confidence, position |
Video Management |
|
| On-camera recording: | Support for microSD/microSDHC/microSDXC card Recording to network-attached storage (NAS) |
| Network video recorders: | Axis NVRs, Milestone Husky NVRs, ONVIF support for 3rd party NVRs |
| Video Management Software: | Axis Camera Station, Milestone XProtect, ONVIF support for 3rd party VMS |
| Cloud: | Milestone Arcules VSaaS, Morphean Cloud CCTV |
General |
|
| System on chip (SoC): | ARTPEC-9, Deep learning processing unit (DLPU) |
| Pan/Tilt/Zoom: | Pan: 360° endless, 0.05°– 150°/s
Tilt: +20 to -90°, 0.05°– 150°/s Nadir flip, 300 preset positions, tour recording (max 10, max duration 16 minutes each), guard tour (max 100), control queue, on-screen directional indicator, set new pan 0° Zoom: 31x optical, 12x digital, Total 372x zoom Adjustable zoom speed |
| Audio: | Input and output through portcast technology |
| Power: | PoE, IEEE802.3bt Class 6
Typical 13 W (no IR), max 51 W Features: power profiles, power meter |
| Connectors: | RJ45 10BASE-T/100BASE-TX/1000BASE-T
RJ45 Push-pull Connector (IP66) Audio: Audio and I/O connectivity via portcast technology |
| Dimensions: | Height: 304 mm (12.0 in)
Width: ø 239 mm (9.4 in) |
| Weight: | 6 200 g (13.7 lb) |
| Casing: | IP66-, NEMA 4X- and IK10-rated3 Colour: white NCS S 1002-B Repaintable metal casing (aluminum), hard coated Polycarbonate (PC) |
| Operating temperatures: | Full power with 60 W midspan: -40 °C to 55 °C (-40 °F
to 131 °F)
Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C (165 °F) Arctic temperature control: Start-up as low as -40 °C (-40 °F) Humidity 10–100% RH (condensing) |
| Warranty: | 5-year |
Security |
|
| Protocols supported: | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Link-Local address (ZeroConf) |
| Edge Security: | Software:
Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, Axis Cryptographic Module (FIPS 140-2 level 1) Hardware: Axis Edge Vault cybersecurity platform Secure element (CC EAL 6+), system-on-chip security (TEE), Axis device ID, secure keystore, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit) |
| Network Security: | IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTSd
, TLS v1.2/v1.3e
, Network Time Security (NTS), X.509
Certificate PKI, host-based firewall |
