Overview of the AXIS Q3839-PVE outdoor multi-sensor camera
- Delivers ultra-clear 8K resolution using four 8.3MP sensors for high-detail panoramic imaging
- Provides seamless image stitching for 180° horizontal and 90° vertical coverage with no blind spots
- Features AI-powered Axis Object Analytics for accurate detection, classification, and counting
- Enhanced clarity in difficult lighting with Lightfinder 2.0 and Forensic WDR
- Includes remote motorised pan, tilt and roll functions to speed up lens alignment and simplify installation
The AXIS Q3839-PVE is a high-performance multi-sensor camera designed for wide-angle coverage of exposed outdoor areas. It combines four 8.3MP sensors offering seamless stitching of all four images for 180° panoramic views in ultra-clear 8K resolution. Horizon straightening compensates for any physical tilt of the camera for reduced image distortion. Lossless zoom allows you to zoom in on sections of the 180° image without degrading resolution, making it easier to examine fine details. With built-in Axis Object Analytics, it enables accurate detection and tracking of people and vehicles. Lightfinder 2.0 and Forensic WDR enhance clarity in low-light scenes.
The unit's casing is IP66/67 and IK10 rated for effective protection against vandalism and harsh weather. Adjust each sensor individually during setup with remote motorised pan/tilt/roll functionality, enabling precise alignment for rapid deployment. This camera can be mounted directly to walls and ceilings with the included mount, and runs over PoE for reduced installation costs.
Video Analytics
AXIS Object Analytics enables fast, reliable detection, classification, and counting of people and vehicles—including cars, lorries, buses, and bikes. Powered by dual ARTPEC-8 chips with deep learning, it runs on the edge for quicker alerts and fewer false alarms by ignoring irrelevant motion like animals or wind. Detected objects are colour-coded with bounding boxes, and up to 10 rules such as line crossing or area occupancy can be defined to boost awareness and insights.
This camera also supports other AXIS and third-party applications, enabling greater functionality for the camera to meet more specialist demands.
Recording and Video Management
See below for available recording and video management options for this camera:
- Record directly to on-board microSD Card (not included)
- AXIS Camera Station Software
- AXIS Camera Station NVRs
- Milestone XProtect video management software
- Milestone Arcules VSaaS
Example Use Cases
Designed for expansive outdoor areas, the AXIS Q3839-PVE delivers high-resolution panoramic monitoring even in challenging weather. Ideal applications include:
- Large car parks and stadiums
- Transport hubs such as bus and train stations
- Industrial complexes and logistics centres
- City centres, parks, and public gathering spaces
- University campuses and school grounds
Included Accessories
- Camera
- Weathershield
- Installation guide
- Drill template
- Connector guard
- Cable gaskets
- Conduit adapter
- I/O connector
- Owner authentication key
Key technical features of the AXIS Q3839-PVE outdoor multi-sensor camera
Camera |
|
| Environment: | outdoor |
| Type: | Fixed multi-sensor dome |
| Sensor: | 4 x 8.3 MP 1/1.8” progressive scan RGB CMOS
Pixel size 2.0 µm |
| Lens: | Horizontal field of view: 180°
Vertical field of view: 90° Fixed iris |
| Day/night: | automatically removable infrared-cut filter |
| Camera adjustment: | Pan ±176°, tilt 30° to 88°, roll ±7° |
| Minimum illumination: | Colour: 0.16 lux at 30 IRE, F2.0
B/W: 0.06 lux at 30 IRE, F2.0 |
| IR illumination: | N/A |
Imaging |
|
| Resolution: | 7552x3776 to 512x256 |
| Frame rate: | Up to 25/30 fps (50/60 Hz) in all resolutions |
| WDR: | Forensic WDR: Up to 120 dB depending on scene |
| Video streaming: | Up to 20 unique and configurable video streams1
Axis Zipstream technology in H.264, H.265 and AV1 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265/AV1 Low latency mode Video streaming indicator |
| Image settings: | Horizon straightening, saturation, contrast, brightness, sharpness, white balance, day/night threshold, local contrast, tone mapping, exposure mode, compression, dynamic text and image overlay, privacy masks, polygon privacy mask |
| Multi-view streaming: | Up to 8 individually cropped out view areas |
| Installation aids: | Pixel counter, remote zoom and focus, straighten image, level grid, leveling assistant |
| Pan/Tilt/Zoom: | Digital PTZ
Control queue Lossless zoom |
Analytics |
|
| Applications: | Included
AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, active tampering alarm, audio detection Supported Support for AXIS Camera Application Platform enabling installation of third-party applications |
| Axis Object Analytics (AOA): | Object classes: humans, vehicles (types: cars, buses,
trucks, bikes, other)
Scenarios: line crossing, object in area, time in area, crossline counting, occupancy in area, tailgating detection, PPE monitoringBETA, motion in area, motion line crossing Up to 10 scenarios Other features: triggered objects visualized with trajectories, color-coded bounding boxes and tables Polygon include/exclude areas Perspective configuration ONVIF Motion Alarm event |
| Axis Scene Metadata: | Object classes: humans, faces, vehicles (types: cars,
buses, trucks, bikes), license plates
Object attributes: vehicle color, upper/lower clothing color, confidence, position |
Video Management |
|
| On-camera recording: | Support for microSD/microSDHC/microSDXC card Recording to network-attached storage (NAS) |
| Network video recorders: | Axis NVRs, Milestone Husky NVRs, ONVIF support for 3rd party NVRs |
| Video Management Software: | Axis Camera Station, Milestone XProtect, ONVIF support for 3rd party VMS |
| Cloud: | Milestone Arcules VSaaS, Morphean Cloud CCTV |
General |
|
| System on chip (SoC): | Dual ARTPEC-8 |
| Audio: | Audio input
Input for external unbalanced microphone, optional 5 V microphone power Digital input, optional 12 V ring power Unbalanced line input Audio output Output via network speaker pairing |
| Power: | Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 2
Class 4
Typical 9.74 W, max 19.1 W Feature: power meter |
| Connectors: | Network: Shielded RJ45 1000BASE-T PoE
Audio: 3.5 mm mic/line in Power: Terminal block I/O: Terminal block for two configurable supervised inputs / digital outputs (12 V DC output, max load 50 mA) |
| Dimensions: | For the overall product dimensions, see the dimension drawing
in the product datasheet.
Effective Projected Area (EPA): 0.038 m2 (0.12 ft2 |
| Weight: | 3320 g (7.3 lb) |
| Casing: | IP66-/IP67-, NEMA 4X- and IK10-rated
Aluminum casing, polycarbonate (PC) dome, sunshield (PC/ASA) Colour: white NCS S 1002-B For repainting instructions, go to the product’s support page |
| Operating temperatures: | -40 °C to 50 °C (-40 °F to 122 °F)
Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C (165 °F) Installation temperature: -20 °C (-4 °F)3 Start-up temperature: -40 °C (-40 °F)4 Humidity 10–100% RH (condensing) |
| Warranty: | 5-year |
| Firmware support to: | 31-12-2033 |
| Protocols supported: | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS2 , HTTP/ 2, TLS2 , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Edge Security: | Software: Signed OS, brute force delay protection,
digest authentication and OAuth 2.0 RFC6749 OpenID
Authorization Code Flow for centralized ADFS account management, password protection, Axis Cryptographic Module (FIPS 140-2 level 1) Hardware: Axis Edge Vault cybersecurity platform Secure keystore: Secure element (CC EAL 6+, FIPS 140- 3 Level 3), system-on-chip security (TEE) Axis device ID, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit) |
| Network Security: | IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)3 , IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTS3 , TLS v1.2/v1.33 , Network Time Security (NTS), X.509 Certificate PKI, host-based firewall |
