Camera |
Environment: |
indoor, outdoor with enclosure |
Type: |
block camera |
Sensor: |
1/1.2” progressive scan RGB CMOS
Pixel size 2.9 µm |
Lens: |
IR corrected, P-iris control
13 mm lens:
Varifocal, 5.9–13.3 mm, F1.6–2.9
Horizontal field of view: 108°–49°
Vertical field of view: 58°–27°
Minimum focus distance: 0.5 m (1.6 ft)
48 mm lens:
Varifocal, 15.2–48.7 mm, F1.7
Horizontal field of view: 42°–13°
Vertical field of view: 24°–7°
Minimum focus distance: 1.5 m (4.9 ft)
|
PTZ: |
Digital PTZ, preset positions, preset position tour
Uploadable PTZ driver (Pelco D, Visca and APTP pre-installed) |
Audio: |
Input for external balanced or unbalanced microphone
Digital input, optional 12 V ring power
Balanced or unbalanced line input
Input through microphone pairing |
Power: |
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3
Typical: 7.5 W, max 12.95 W
10–28 V DC, typical 7.0 W, max 12.95 W
|
Imaging |
Resolution: |
16:9:3840x2160 to 160x90
16:10: 2560x1600 to 160x100
4:3: 2592x1944 to 160x120
|
Frame rate: |
With WDR: Up to 25/30 fps (50/60 Hz) in all resolutions
No WDR: Up to 50/60 fps (50/60 Hz) in all resolutions |
IR illumination: |
N/A |
WDR |
Forensic WDR: Up to 120 dB depending on scene |
Video streaming: |
Up to 20 unique and configurable video streams
Axis Zipstream technology in H.264, H.265 and AV1
Controllable frame rate and bandwidth
VBR/ABR/MBR H.264/H.265/AV1
Low latency mode
Video streaming indicator |
Day/night: |
Automatic IR-cut filter in day mode
Hybrid IR filter |
Minimum illumination: |
13 mm lens:
With WDR and Lightfinder
Colour: 0.05 lux at 50 IRE, F1.6–2.9
B/W: 0.01 lux at 50 IRE, F1.6–2.9
48 mm lens:
With WDR and Lightfinder
Colour: 0.05 lux at 50 IRE, F1.7
B/W: 0.01 lux at 50 IRE, F1.7 |
Remote zoom / focus |
included |
Image settings: |
Saturation, contrast, brightness, sharpness, white balance,
day/night threshold, local contrast, tone mapping, exposure
mode, exposure zones, defog, barrel distortion correction,
electronic image stabilization, compression, rotation: auto, 0°,
90°, 180°, 270° including corridor format, mirroring, dynamic
text and image overlay, overlay widget, polygon and mosaic
privacy mask, target aperture
Scene profiles: forensic, vivid, traffic overview
|
Analytics |
Applications: |
Included
AXIS Object Analytics, AXIS Scene Metadata, AXIS Image Health Analytics, AXIS Live Privacy Shield, AXIS Speed Monitor
AXIS Video Motion Detection
Supported
AXIS License Plate Verifier
Support for AXIS Camera Application Platform enabling installation of third-party applications |
Axis Object Analytics: |
Object classes: humans, vehicles (types: cars, buses, trucks,
bikes, other)
Scenarios: line crossing, object in area, time in area, crossline
counting, occupancy in area, motion in area, motion line crossing
Up to 10 scenarios
Other features: triggered objects visualized with trajectories,
colour-coded bounding boxes and tables
Polygon include/exclude areas
Perspective configuration
ONVIF Motion Alarm event |
Axis Image Health Analytics: |
Detection settings:
Tampering: blocked image, redirected image
Image degradation: blurred image, underexposed image
Other features: sensitivity, validation period |
Axis Scene Metadata: |
Object classes: humans, faces, vehicles (types: cars, buses,
trucks, bikes), license plates
Object attributes: vehicle colour, upper/lower clothing colour,
confidence, position |
Video Management |
Video compression: |
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
H.265 (MPEG-H Part 2/HEVC) Main Profile
Motion JPEG
AV1 |
On-camera recording: |
Support for microSD/microSDHC/microSDXC card
Support for SD card encryption (AES-XTS-Plain64 256bit)
Recording to network-attached storage (NAS) |
Network video recorders: |
Axis NVRs, Milestone Husky NVRs, ONVIF support for 3rd party NVRs |
Video Management Software: |
Compatible with AXIS Camera Station Edge, AXIS Camera Station
Pro, AXIS Camera Station 5, Milestone XProtect |
Cloud: |
Eagle Eye Networks, Morphean Cloud CCTV |
General |
Connectors: |
Network: Shielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE
I/O: 6-pin 2.5 mm terminal block for four configurable inputs
Serial communication: RS485/RS422, 2 pcs, 2 pos, full duplex, terminal block
Audio: 3.5 mm mic/line in
Power: DC input, terminal block
HDMI Type D
AHI (Axis Housing Interface)
Security lock slot |
Dimensions: |
For the overall product dimensions, see the dimension drawing
in the datasheet.
|
Weight: |
13 mm lens: 529 g (1.2 lb)
48 mm lens: 611 g (1.3 lb) |
Casing: |
Aluminum and plastic casing
Colour: NCS S 9000-N
|
Materials: |
Renewable carbon-based plastic content
13 mm lens: 37% (recycled)
48 mm lens: 42% (recycled)
Screened for conflict minerals in accordance with OECD
guidelines
|
Operating temperatures: |
Temperature: -10 °C to 60 °C (14 °F to 140 °F)
Humidity: 10–85% RH (non-condensing)) |
Installation aids: |
Remote zoom and focus, Pixel counter, Traffic camera installation assistance |
Warranty: |
5-year |
Protocols supported: |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb
, HTTP/2, TLSb
,
QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour),
UPnP®
, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS,
RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP,
DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog
(RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
Security |
Edge security: |
Software: Signed OS, brute force delay protection, digest
authentication and OAuth 2.0 RFC6749 OpenID Authorization
Code Flow for centralized ADFS account management, password
protection
Hardware: Axis Edge Vault cybersecurity platform
Secure element (CC EAL 6+, FIPS 140-3 Level 3), system-on-chip
security (TEE), Axis device ID, secure keystore, signed video,
secure boot, encrypted filesystem (AES-XTS-Plain64 256bit)
|
Network security: |
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)b
, IEEE 802.1AR,
HTTPS/HSTSb
, TLS v1.2/v1.3b
, Network Time Security (NTS), X.509
Certificate PKI, host-based firewall
|
