Bosch Security | VJT-X40S
Bosch Videojet X40 rugged compact video encoder with 2-way audio and compact flash recording – 4 port
This product is discontinued, for alterative models please see Network Video Encoders And Decoders
The Bosch Videojet X40 is a 4-port video server built into a rugged industrial-grade housing suitable for outdoor applications and harsh environments.
The encoder has 4 analogue video inputs which allows up to 4 existing analogue CCTV cameras to integrate into a digital IP infrastructure. This provides streaming video to be broadcast over digital IP networks and gives digital IP benefits such as remote access to live images over the Internet as well as intelligent video applications such as video motion detection and tampering alarm activity.
Heavy-duty construction enables the encoder to be used in outdoor applications and in extreme environmental conditions. Industrial-grade vibration resistance also makes this encoder ideal for use in public transport vehicles such as buses and trains etc. Like all products on offered by Network Webcams, the Bosch Videojet X40 has a built-in web server and can be viewed over a Local Area Network (LAN), Wide Area Network (WAN) or via the Internet.
Bosch Videojet X40 - Key benefits:
- Heavy-duty construction allows the encoder to be used in industrial and outdoor applications
- Allows legacy analogue CCTV equipment to be integrated into a digital IP CCTV system protecting your initial investment and providing a clear path a to fully digital IP CCTV solution
- Flexible recording options using local storage allows the encoder to record without the requirement for a network connection
Bosch Videojet X40 - Key features:
- 4-port video encoder will take up to 4 analogue video sources (BNC connection, PAL/NTSC)
- Rugged construction, can be used outdoors and in industrial environments prone to harsh conditions
- Industrial-grade vibration resistance allows the use in public transport vehicles such as buses or trains
- Compact size, takes very little room in a CCTV monitoring control room
- 2-way audio support allows 2-way communication between people at the encoder and people in the control room
- High quality MPEG-4 encoding with dual streaming capabilities for viewing and recording of 2 independent streams with different quality settings to save bandwidth or storage space
- MOTION+ motion detection built-in for video content analysis with object size filtering capabilities
- Active tampering alarm alerts the user if a camera has been blocked or moved
- Recording options include local storage to Compact Flash memory card, USB external hard disk drive, iSCSI network devices or to traditional Network Video Recorders (NVR)
- RAID5 iSCSI storage allows the Videojet X40 to act as a conventional DVR interfacing directly with iSCSI storage devices
- The encoder can store up to 10 programmable recording profiles. These allow you to adjust the frame-rate or resolution of a specific video stream based on alarm activity
- External alarm inputs allows the recording of images based on external devices such as switches, doorbells, window sensors etc.
- Relay outputs allows external devices to be controlled through the unit such as an audible alarm or a light
- Viewing can be achieved using a standard Internet browser such as Internet Explorer or in a VIDOS monitor wall or Bosch video management system
- Security comprises of multi-level user logins, 802.1x authentication using a RADIUS server and SSL encryption by secure HTTPS connection. For total data protection the data channel can be AES encrypted with a 128bit key
- Intelligent Video Motion Detection (IVMD) and is optional licensed video content analysis software which can be installed to provide intelligent functionality such as adapting to global lighting changes and weather conditions, detection of objects entering or leaving an area, direction of travel or speed of object. (software not supplied as standard)
- Intelligent Video Analysis (IVA) software can also be added as an option for multi-level image analysis functions
Bosch Videojet X40 - Typical applications:
- Suitable for the integration of up to 4 analogue video sources into a digital IP-based network for industrial applications in harsh environments such as gate and perimeter control, warehousing, factories, construction sites etc. Also suitable for use on public transportation such as trains, buses or other vehicles
Bosch Videojet X40 - Key technical indicators:
- Video compression: MJPEG, JPEG, MPEG-4
- Number of analogue ports: 4 (BNC connection)
- Video signal: Analogue composite, NTSC or PAL
- Supported resolutions: (PAL) 704x576, 704x288, 464x576, 352x576, 352x288, 174x144, (NTSC) 704x480, 704x240, 464x480, 352x480, 352x240, 176x120
- Frame-rate: 25fps (PAL), 30fps (NTSC)
- Audio: 2-way, external microphone and speaker system required (not supplied)
- Audio compression: G.711; 300Hz to 3.4Hz
- Supported protocols: RTP, Telnet, UDP, TCP, IP, HTTP, HTTPS, FTP, IGMP V2/V3, ICMP, ARP, RTSP, SMTP, SNTP, SNMP (V1, MIB-II), 802.1x
- Power: Input voltage: 10-30V DC
- Weight: 1.5kg (3.3lb)
- Operating temperatures: -30°C to 60°C (-22°F to 140°F)
- Dimensions: (HxWxD) 61 x 178 x 160mm
Bosch Videojet X40 - Connections:
- Ethernet: Dual-port Ethernet 10/100Base-T, auto-sensing, half/full-duplex, RJ-45
- Video in: 4x analogue composite, NTSC/PAL, BNC connection
- SFP: 1x 1Gbps SFP (small form-factor pluggable) slot for optional standard SFP GBIC module
- 1x audio mono line in (3.5mm jack connection)
- 1x mono line out (3.5mm jack connection)
- Alarm in: 4x clamp (non-isolated closure contact type)
- Relay out: 4x clamp 30 Vpp. 2A
- Compact Flash slot for optional standard CF Type I/II Compact Flash memory card
- USB port: 2x 2.0 external interface, 2.5W max feed each
Bosch Videojet X40 - Accessories included:
- VJT-XACC-PSUK wide range extended temperature power supply
- Quick installation guide
- CD-ROM with software and documentation
- Drilling template
- Set of spring clamp contact connectors
Bosch Videojet X40 - Additional items you may want to order with this camera:
- VJT-X40-FS1 – Videojet X40 IVMD (Intelligent Video Motion Detection) 1.0 VCA software license
- VJT-X40-FS3 – Videojet X40 IVA (Intelligent Video Analysis) 3.0 software license
