| VJT-X20S

Bosch Videojet X20 rugged compact video encoder with 2-way audio and compact flash recording – 2 port

Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Hurry! Only left

This product is discontinued, for alterative models please see Network Video Encoders And Decoders

The Bosch Videojet X20 is a rugged, dual-input encoder suitable for converting up to 2 legacy analogue video streams for broadcast over IP digital networks. This provides IP camera benefits such as remote access to live video across the network or Internet as well as intelligent applications such as motion detection and tampering alarm activity.

The encoder includes a number of flexible recording options including built-in Compact Flash recording, external USB hard drive or network attached iSCSI devices. It also provides an audio line input and output for 2-way communication.

Rugged construction makes this encoder suitable for industrial applications in areas with extreme environmental conditions such as perimeter, gate, fence control as well as installation on public transportation vehicles such as trains and buses. Like all products on offered by Network Webcams, the Bosch Videojet X20 has a built-in web server and can be viewed over a Local Area Network (LAN), Wide Area Network (WAN) or via the Internet.

Bosch Videojet X20 - Key benefits:

  • Rugged construction, designed for heavy-duty use in industrial environments and areas with extreme temperature conditions
  • Promotes hybrid connectivity. Allows the use of existing analogue CCTV cameras by integrating them into a digital IP infrastructure. Protect your initial analogue investment while migrating to a digital IP system at your own pace
  • Flexible recording options using local storage allows the encoder to record without the requirement for a network connection

Bosch Videojet X20 - Key features:

  • 2-port video encoder will take up to 2x analogue video sources (BNC connection, PAL/NTSC)
  • Rugged construction, can be used outdoors and in industrial environments
  • Vibration resistance allows the use in public transport vehicles such as buses or trains
  • Compact size takes very little room
  • 2-way audio support allows you to not only listen-in to the area where the encoder is placed but also talk-back to people at the encoder’s location. Issue instructions to staff members or sound warnings to potential intruders etc.
  • High quality MPEG-4 encoding with dual streaming capabilities for viewing and recording of 2 independent streams with different quality settings to save bandwidth or storage space
  • MOTION+ motion detection built-in for video content analysis with object size filtering capabilities and sophisticated tamper detection capabilities
  • Recording options include local storage to Compact Flash memory card, USB external hard disk drive, iSCSI network devices or to traditional Network Video Recorders (NVR)
  • RAID5 iSCSI storage allows the Videojet X20 to act as a conventional DVR interfacing directly with iSCSI storage devices
  • The encoder can store up to 10 programmable recording profiles allowing you to perform actions such as increase the frame-rate or resolution on alarm
  • External alarm inputs (4x) allows the recording of images based on external devices such as switches, doorbells, window sensors etc.
  • Relay outputs (4x) allows external devices to be controlled through the unit such as an audible alarm or a light
  • Viewing can be achieved using a standard Internet browser such as Internet Explorer or in a VIDOS monitor wall or Bosch video management system
  • Security comprises of multi-level user logins, 802.1x authentication using a RADIUS server and SSL encryption by secure HTTPS connection. For total data protection the data channel can be AES encrypted with a 128bit key
  • Intelligent Video Motion Detection (IVMD) and is optional licensed video content analysis software which can be installed to provide intelligent functionality such as adapting to global lighting changes and weather conditions, detection of objects entering or leaving an area, direction of travel or speed of object. (software not supplied as standard)
  • Intelligent Video Analysis (IVA) software can also be added as an option for multi-level image analysis functions

Bosch Videojet X20 - Typical applications:

  • Suitable for the integration of up to 2 analogue video sources into a digital IP-based network for industrial applications in harsh environments such as gate and perimeter control, warehousing, factories, construction sites etc. Also suitable for use on public transportation such as trains, buses or other vehicles

Bosch Videojet X20 - Key technical indicators:

  • Video compression: MJPEG, JPEG, MPEG-4
  • Number of analogue ports: 2 (BNC connection)
  • Video signal: Analogue composite, NTSC or PAL
  • Supported resolutions: (PAL) 704x576, 704x288, 464x576, 352x576, 352x288, 174x144, (NTSC) 704x480, 704x240, 464x480, 352x480, 352x240, 176x120
  • Frame-rate: 25fps (PAL), 30fps (NTSC)
  • Audio: 2-way, external microphone and speaker system required (not supplied)
  • Audio compression: G.711; 300Hz to 3.4Hz
  • Supported protocols: RTP, Telnet, UDP, TCP, IP, HTTP, HTTPS, FTP, IGMP V2/V3, ICMP, ARP, RTSP, SMTP, SNTP, SNMP (V1, MIB-II), 802.1x
  • Power: Input voltage: 10-30V DC
  • Weight: 1.5kg (3.3lb)
  • Operating temperatures: -30°C to 60°C (-22°F to 140°F)
  • Dimensions: (HxWxD) 61 x 178 x 160mm

Bosch Videojet X20 - Connections:

  • Ethernet: Dual-port Ethernet 10/100Base-T, auto-sensing, half/full-duplex, RJ-45
  • Video in: 1x analogue composite, NTSC/PAL, BNC connection
  • SFP: 1x 1Gbps SFP (small form-factor pluggable) slot for optional standard SFP GBIC module
  • 1x audio mono line in (3.5mm jack connection)
  • 1x mono line out (3.5mm jack connection)
  • Alarm in: 4x clamp (non-isolated closure contact type)
  • Relay out: 4x clamp 30 Vpp. 2A
  • Compact Flash slot for optional standard CF Type I/II Compact Flash memory card
  • USB port: 2x 2.0 external interface, 2.5W max feed each

Bosch Videojet X20 - Accessories included:

  • VJT-XACC-PSUK wide range extended temperature power supply
  • Quick installation guide
  • CD-ROM with software and documentation
  • Drilling template
  • Set of spring clamp contact connectors

Bosch Videojet X20 - Additional items you may want to order with this encoder:

  • VJT-X20-FS1 – Videojet X20 IVMD (Intelligent Video Motion Detection) 1.0 VCA software license
  • VJT-X20-FS3 – Videojet X20 IVA (Intelligent Video Analysis) 3.0 software license
