| 0454-001

Axis P8514 Indoor compact, eye-level IP camera with HD720p resolution, H.264 and pixel counter

Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Hurry! Only left

This product is discontinued, for alternatives please see Axis IP Cameras

Overview of the Axis P8514 (0454-001)

The Axis P8514 IP camera is designed for unobtrusive surveillance in shops or business receptions. The camera features a pinhole camera for disctreet, unobtrusive surveillance. The camera is also mounted at eye level.

People in view can be easily identified by the Axis P8514 IP camera, even from a distance since the camera offers HD720p video with smooth, sharp footage. Video can be encoded with H.264 video compression, reducing bandwidth usage and hard drive storage requirements while still maintaining a high image quality.

Installation is very straight forward as the camera comes with mounting clamps included as well as a pre-mounted Ethernet connection. The camera's Pixel Counter system lets installers veryfy that adequate resolution is available for facial identification, while power over Ethernet support lets the camera draw power from a centralized location, so no additional electrical cabling is required.

Please note: This camera is available in multiple paint finishes. Please make your selection above when ordering. Additionally, this camera does not come with a power supply and can be added to the order using the options above.

Key features & benefits of the Axis P8514 (0454-001)

  • The camera is mounted at eye-level so cannot be circumvented with hats or long hair
  • Images can be captured unobtrusively as the camera resembles pipes or trunking
  • Multiple paint finishes are available so the camera can blend in more easily with the surroundings
  • Capture HD720p video, ensuring that even from a distance pleple can be easily recognized
  • Pixel counter system lets installers ensure that adequate resolution is available for faces in view
  • H.264 support minimizes hard drive requirements for recording without compromising on image quality

Typical applications of the Axis P8514 (0454-001)

The Axis P8514 would be ideal for various areas where facial images need to be captured non-invasively, such as service stations, small business receptions, shops and public transport terminals.

Accessories for the Axis P8514 (0454-001)


  • Axis P8514 mini camera in your choice of paint finish (selectable above)
  • Clamps
  • Installation guide
  • Height indicator decal (Black/chrome only, pre-fitted on white version)
Back To Top

Key technical features for the Axis P8514 (0454-001)

Environment: indoor
Type: compact, fixed camera
Sensor: 1/4" progressive scan RGB CMOS
Lens: fixed 3.7mm (F1.8) lens with 57deg; horizontal viewing angle
Power: Power over Ethernet IEEE 802.3af Class 1
Processor/memory: ARTPEC-3 processor, 128 MB RAM and 128 MB Flash
Resolution: 1280x800 to 160x90 pixels (1440x900 available through CGI commands)
Compression: H.264 and MJPEG
Frame-rate: 30fps in all resolutions
Bandwidth control: controllable frame rate and bandwidth
Minimum illumination: 1 lux @ F1.8
Digital zoom/PTZ: digital PTZ with preset positions and guard tour
Video overlay: text and image overlay
Imaging: adjustable compression, colour, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, wide dynamic range - dynamic contrast, fine tuning of behaviour in low light, mirroring of images and rotation
Viewing, detection & recording
Privacy masking: yes
Simultaneous users: 20
Alarm detection: intelligent video
Intelligent video: video motion detection and active tampering alarm
Alarm notifications: file upload or notification via FTP, HTTP and email pre- and post-alarm video buffering
Recording software included: Axis Camera Station One single-channel
Compatible recording platforms (not included)
Software:Axis Camera Station, Milestone XProtect, SecuritySpy (for Mac OSX)
Network Video Recorders:QNAP
Network: Female 10/100Mbps RJ-45 connection with IEEE802.3af PoE
Dimensions: 2830mm x 51mm
Weight: 4.5 kg
Colour: selectable above (white, black or chrome)
Warranty: 3-year manufacturer's warranty
Mounting methods: wall-mountable (clamps included)
Operating temperatures:0-50 °C
Power consumption: 3.2W
Dynamic DNS: Axis' own dynamic DNS service
Protocols supported: IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
QoS: Yes
Security: password protection, IP address filtering, digest authentication, HTTPS encryption, IEEE 802.1X, user access log
ONVIF compliant: yes
