Axis Communications | 01809-001
Axis P1377-LE outdoor-ready IP camera with i-CS mount lens, 5 megapixel resolution, 50m OptimisedIR, Lightfinder and PoE
This product is discontinued. The replacement model is
Axis P1387-LE.
Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
This versatile IP camera is an ideal choice for deployment in exposed outdoor locations where reliable 24-hour monitoring is required. It features OptimisedIR technology, an i-CS mount lens and advanced Axis imaging technologies.
- 5MP resolution
- Varifocal lens: 90°-38° viewing angle
- Up to 50m OptimisedIR illumination
- Multi-view streaming supported
- Forensic WDR, Lightfinder & EIS supported
- Axis 5-year warranty
This model is now discontinued, it has been replaced with the Axis P1387-LE outdoor varifocal box IR camera
Overview of the Axis P1377-LE
Part of the Axis P13 series, this outdoor-ready IP camera delivers 5 megapixel resolution at up to 30 frames per second (fps), as well as offering support for both CS and intelligent CS-mount lenses (i-CS). The unit's integrated infrared (IR) LEDs help to enhance night vision at a range of up to 50m, whilst a vandal-resistant and IP67-rated casing allows the camera to be safely deployed in exposed locations. Additional features include support for Power-over-Ethernet (PoE) and a range of advanced imaging technologies for clear image capture - in any lighting condition.
This innovative, outdoor-ready CS-mount IP camera offers support for both CS- and intelligent CS-mount lenses (i-CS). The varifocal lens offers viewing angles between 38° - 90° and allows optimum scene coverage to be set during installation. To help simplify installation, the i-CS lens features several integrated motors which allow, users to remotely adjust lens settings. Additionally, areas of interest can be monitored closely using the multi-streaming feature, which allows up to 8 specific regions in the field of view to be cropped and streamed separately for live viewing or recording.
The model features integrated IR LEDs that extend the camera's night-vision range up to 50m. Axis' OptimisedIR technology ensures an evenly illuminated image by automatically adapting the angle of illumination to the zoom level set. Forensic WDR ensures the capture of details in high-contrast scenes and Axis’ Lightfinder technology provides full colour viewing in ambient light extremes. If the camera is subject to vibrations, Axis' Electronic Image Stabilisation (EIS) technology ensures video is smooth and steady despite camera movement.
Configurable video motion detection alarms can be set to send alerts of activity to the user via email notification; and when used in conjunction with Axis Guard Suite analytics, these alerts can prompt certain tasks such as digitally moving to a pre-set location within the field of view. Additionally, integrated shock detection triggers the camera to send an alarm if the unit is hit - providing reliable, real-time detection of vandalism attempts.
With support for High Power-over-Ethernet (PoE+), the camera is supplied with both power and network connectivity via a single cable – simplifying installation. Axis’ Zipstream technology helps to lower bandwidth and storage levels by an average of up to 50%. It optimises the video stream in real-time, allowing important details to be retained while unnecessary data is removed. Additionally, this model includes a range of handy features to assist in the prevention of unauthorised access. Signed firmware and secure boot also help to ensure the integrity and authenticity of the camera's firmware.
Please note: there is no power supply included with this unit. It is power over ethernet capable.
Key features & benefits
- Capable of delivering 5 megapixel resolution at 30 fps or HD 720p resolution at up to 180 fps - for detailed CCTV footage in busy locations
- True day/night functionality with IR cut filter provides round-the-clock monitoring
- CS-mount varifocal lens allows optimum scene coverage to be set during installation
- Varifocal lens (2.8mm - 8mm) offers horizontal viewing angles from 38° to 111°
- Robust IK10 and IP67-rated casing makes the camera suitable for use in exposed outdoor areas
- Integrated IR LEDs with OptimisedIR technology provide even illumination at a range of up to 50m
- Multiple areas of the original image can be cropped and viewed simultaneously using multi-view streaming
- Forensic WDR improves visibility and ensures the capture of details in high-contrast scenes
- Axis Lightfinder increases light sensitivity for improved video capture in very low light
- Electronic Image Stabilisation (EIS) technology offsets the effect of camera movement - ensuring video is clear and not blurred
- Two-way audio is supported with the connection of a microphone and speaker (not included)
- External devices can be connected via alarm I/O ports for enhanced alarm signalling
- Configurable audio, video motion detection and tampering alarms help to enhance security monitoring
- Pre-loaded with a range of advanced security functionalities to help increase the cyber defence
- Axis’ Zipstream technology helps to reduce bandwidth and storage requirements
- Internal storage via Micro SD card (not included) provides a simple backup solution in the event of network failure
- Support for power and network connectivity through PoE enables simple and cost-effective installation
Compatible recording platforms
Typical applications
The Axis P1377-LE is an advanced CCTV solution that delivers reliable, 24-hour monitoring of exposed outdoor locations in 5 megapixel resolution. Typical applications include warehouses, train station terminals and government grounds.
Accessories
Included:
- Installation Guide
- Wall mount bracket
- Windows decoder 1-user license
- Torx T20 screwdriver
- Torx T30 screw bit
- Connector kit IK10 tool
- Axis P13 Weathershield Kit A
- Pre-mounted Axis Fixed Box IR Illuminator Kit A
Optional:
- PoE Midspan
- MicroSD card
Mounting options
- Wall mounting - accessories included
- Pole mounting - Axis T91B47
- Parapet mounting - Axis T99A12
Key technical features of the Axis P1377-LE
Camera |
|
| Environment: | outdoor |
| Type: | fixed |
| Sensor: | 1/2.7” progressive scan RGB CMOS |
| Lens: | IR corrected, CS-mount lens, P-Iris Varifocal 2.8–8 mm, F1.2 Horizontal field of view: 90°–38° Vertical field of view: 67°–28° |
| Audio: | two-way, full duplex |
| PTZ: | digital PTZ, uploadable PTZ driver (Pelco D pre-installed) |
| Power: | 12–28 V DC, max 9.7 W, typical 5.3 W Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3, max 10.7 W, typical 5.4 W Power redundancy |
| Memory: | 1 GB RAM, 512 MB Flash |
Video |
|
| Resolution: | 2592x1944 (5 MP) to 160x90 2688x1512 (4 MP) to 160x90 1280x720 (HDTV 720p) to 160x9 |
| Compression: | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles H.265 (MPEG-H Part 2/HEVC) Motion JPEG Controllable frame rate and bandwidth |
| Frame-rate: | 5MP: 25/30 fps, 4MP: 25/30 fps, HD 720p: 180 fps |
| Bandwidth control: | multiple, individually configurable streams in H.264, H.265, and Motion JPEG, Axis Zipstream technology in H.264 and H.265, controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265, video streaming indicator |
| Day/night: | automatically removable infrared cut-filter, OptimizedIR with power-efficient, long-life 850 nm IR LEDs, range 50m |
| Minimum illumination: | HD 1080p 25/30 fps with Forensic WDR and Lightfinder: colour: 0.13 lux, at 50 IRE F1.2, B/W: 0.03 lux, at 50 IRE F1.2 0 lux with IR illumination on |
| Video overlay: | text and image |
| Imaging: | saturation, contrast, brightness, sharpness, Forensic WDR: Up to 120 dB depending on scene, white balance, day/night threshold, exposure mode, exposure zones, local contrast, tone mapping, compression, orientation: auto, 0°, 90°, 180°, 270° including Corridor Format, mirroring of images, dynamic text and image overlay, privacy masks, defogging, electronic image stabilisation, barrel distortion correction, scene profiles: forensic, vivid, traffic overview |
| Onscreen controls: | electronic image stabilisation, day/night shift, defogging, wide dynamic range |
Viewing, detection & recording |
|
| Privacy masking: | yes |
| Number of users: | not given |
| Alarm detection: | Axis video motion detection , active tampering alarm, audio detection, shock detection, open casing, edge storage events, supervised external input, audio level, time scheduled |
| Alarm action: | file upload: FTP, SFTP, HTTP, HTTPS, network share and email, notification: email, HTTP, HTTPS and TCP, external output activation, video recording to edge storage, Play audio clip Pre- and post-alarm video buffering ,PTZ preset, Guard tour, overlay text Day/Night switching, status LED activation, send SNMP trap |
| Pre-/post-alarm buffer: | yes |
| On-camera recording: | support for microSD/microSDHC/microSDXC card |
| Direct-to-NAS storage: | yes |
| Recording software supported: | Axis Camera Station, Axis Companion |
Connections |
|
| Power: | 12–28 V DC, max 19.1W, typical 10.5W Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 2 Class 4, max 20.4W, typical 11.1W, with disabled IR: Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3, max 12.95W, typical 6.7W Power redundancy |
| Network: | RJ45 10BASE-T/100BASE-TX/1000BASE-T |
| Other: | I/O: 6-pin 2.5 mm terminal block, for 2 supervised alarm inputs and 2 outputs RS485/RS422, 2 pcs, 2 pos, full duplex, terminal block DC input, terminal block 3.5 mm mic/line in, 3.5 mm line out i-CS connector (compatible with P-Iris and DC-iris) |
Other |
|
| Dimensions: | 404 x 159 x 168 mm |
| Weight: | 2.4kg |
| Casing: | IP66-, IP67- and NEMA 4X-rated, IK10 impact-resistant polymer enclosure with aluminium base and intrusion alarm switch, weathershield with black anti-glare coating, colour: White NCS S 1002-B |
| Warranty: | 5 years |
| Mounting methods: | wall mount bracket |
| Operating temperatures: | -40°C to 60°C |
| Power consumption: | max 10.5W |
| Dynamic DNS: | yes |
| Protocols supported: | IPv4, IPv6 USGv6, HTTP, HTTPSa, SSL/TLSa, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
| QoS: | yes |
| Security: | password protection, IP address filtering, HTTPSa encryption, IEEE 802.1X (EAP-TLS) a network access control, digest authentication, user access log, centralized certificate management, brute force delay protection, signed firmware, secure boot |
| ONVIF compliant: | yes, profile S, G and T |
