Axis Communications | 0337-041
Axis M3204 Surveillance Kit - 4 Axis M3204 HD 720p IP cameras and Axis Camera Station recording software
This product is discontinued, an alternative model is the Axis P3265-V
Overview of the Axis M3204 Surveillance Kit
The Axis M3204 Surveillance Kit allows the fast deployment of a small-scale network-based CCTV camera network. Included are 4 x Axis M3204 IP cameras, with HD 720p resolution to capture sharp, detailed video, and a 4-channel license for Axis Camera Station surveillance software.
The M3204 compact domes are ideal for professional surveillance in indoor environments and can be installed quickly with PoE support. The Axis surveillance software provides powerful monitoring and recording and can be easily extended when required up to 100 IP cameras.
Key features & benefits of the Axis M3204 Surveillance Kit
- Create a professional IP CCTV system with Axis network cameras
- Capture clear HD video footage with clear detail
- Provide professional-level video recording and monitoring with Axis Camera Station
- The system can be easily expanded when required, ideal for staged deployment
Typical applications for the Axis M3204 Surveillance Kit
With HD resolution, this IP camera kit would be ideal for deployment in many locations where the capture of clear facial features is requied, such as store checkouts, cash handling areas, hotels, showrooms, bank foyers and office receptions.
Included accessories for the Axis M3204 Surveillance Kit
- Four Axis M3204 vandal-resistant dome cameras
- Axis Camera Station Setup CD with 4-channel license
Key technical features for the Axis M3204 Surveillance Kit
Camera | |
Environment: | Indoor |
Type: | Tamper-resistant fixed-dome |
Sensor: | 1/4" progressive scan RGB CMOS sensor |
Lens: | 2.8-10 mm (F1.7) varifocal, fixed iris lens with 66-18° horizontal angle of view |
Lens movement: | Pan: 360°. Tilt: 170°. Rotation 340° |
Power: | IEEE802.3af Power over Ethernet (Class 2) |
Processor/memory: | ARTPEC-3 processor with 128MB RAM and 128MB Flash |
Compatibility: | Compatible with Windows, Mac and Linux PCs with Internet Explorer, Firefox, Chrome or Safari browsers |
Video | |
Resolution: | Various resolutions between 1280x800 and 160x190 |
Compression: | H.264 and MJPEG |
Frame-rate: | 30fps in all resolutions and compression formats |
Bandwidth control: | Constant bit rate H.264 |
Day/night: | Day only |
Minimum illumination: | 0.9 lux |
Digital zoom/PTZ: | Browser-controlled digital zoom with presets and guard tour |
Video overlay: | Time stamp, text and image |
Imaging: | Adjustable shutter time, colour, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behaviour at low light, rotation and mirroring of images |
Viewing, detection & recording | |
Privacy masking: | Yes |
Simultaneous users: | 20 |
Alarm detection: | Motion detection, anti-tampering alarm and Axis Camera Application Platform |
Alarm notifications: | File upload via FTP and HTTP, and notification via email, HTTP and TCP |
Recording triggers: | Manual, schedule or alarm |
Pre-/post-alarm buffer: | 25MB |
Recording software included: | Axis Camera Station 4-channel license |
Connections | |
Network: | 10/100Mbps RJ-45 Ethernet connection with PoE support |
Other | |
Dimensions: | ø144mm x 94mm |
Weight: | 430g each |
Colour: | White |
Warranty: | 1 Year manufacturer's warranty |
Mounting methods: | Wall or ceiling mountable (3-axis movement) |
Operating temperatures: | 0-50°C |
Power consumption: | 4.2 W |
Dynamic DNS: | Yes, using Axis' own DDNS service |
Protocols supported: | IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP and SOCKS |
QoS: | Yes |
Security: | Password protection, IP address filtering, HTTPS encryption, digest authentication and user access log |
System integration: | VAPIX SDK available |
ONVIF compliant: | Yes |
