| SD8322E

Vivotek SD8322E outdoor dome IP camera with endless 360 pan, 24x zoom, day/night, WDR Pro, HPoE, SD recording

Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Hurry! Only left

This product is discontinued, for alternatives please see Wisenet IP Cameras

Overview of Vivotek SD8322E

Ideal for surveillance over wide open spaces, the Vivotek SD8322E speed dome IP camera features endless 360° panning and 90° tilt, coupled with 28x optical zoom capturing well-defined, sharp video of both close-in and distant objects. The integrated stability system ensures that the image is kept stable when the camera is mounted on unstable surfaces while its wide dynamic range allows users to clearly observe in both shadowed and over exposed areas simultaneously.

Designed for quick and easy deployment, the camera is outdoor ready so can be installed outdoors without an additional housing, and features an integrated wall-mount bracket. The camera's audio capability allows users to speak interactively with people in view or to trigger events when sound is detected, ideal for sounding alarms or triggering recording.

With switchable day/night modes, the camera captures high quality video in daylight as well as monochrome footage in low light, even in complete darkness when used with infrared illumination (sold separately). The camera's high frame rate of up to 60fps also ensures that even very quick movements are captured, so sleight-of-hand is not missed.

Key features & benefits of the Vivotek SD8322E

  • endless 360° pan and 90° tilt ensures that all angles are covered
  • Zoom in close for detailed video footage with 28x optical zoom
  • Capture in frame rates of up to 60fps, ensuring even the fastest movement is captured
  • Electronic Image Stabilisation prevents the image shake experienced when mounted on unstable surfaces
  • Outdoor-ready, featuring an integrated wall-mount bracket for fast deployment
  • Wide dynamic range technology captures video in light and dark areas simultaneously
  • Support for High Power over Ethernet makes the camera very easy to install, with power and data supplied through the same cable
  • Edge recording to SD memory card provides a reliable, low-cost alternative to centralised recording
  • Combine the camera with infrared lighting for a true 24-hour surveillance solution
  • Listen to events or speak with people in view using 2-way audio
  • Raise alerts based on unexpected noises so that even unseen events can trigger alarms
  • 3D privacy masking protects sensitive areas from being seen

Typical applications of the Vivotek SD8322E

With the large field of view offered by this camera, it's ideal for surveillance of wide open areas such as parks, shopping centres, car parks, site perimeters, school and hospital grounds, warehouses, factories and storage yards.

Included accessories for the Vivotek SD8322E

  • Black cover
  • Clear dome cover
  • Power adapter
  • Wall-mount bracket
  • O-ring and screws
  • Alignment sticker
  • Metal ring
  • Moisture absorber
  • RJ45 female-female coupler
  • Quick installation guide
  • Warranty card
  • Software CD
Back To Top

Key technical features for the Vivotek SD8322E

Environment: Outdoor-ready
Type: Pan-tilt-zoom dome camera
Sensor: 1/4" Sony EXview HAD CCD sensor
Lens: 3.5-98.0mm (F1.35-3.7) auto-iris, auto-focus lens with 2.1-55.8° horizontal viewing angle
PTZ: Endless 360° pan, 90° tilt and 28x optical zoom
Audio: 2-Way bi-directional audio with GSM-AMR, AAC and G.711 compression
Power: High Power over Ethernet (IEEE802.3at) or 24V AC
Compatibility: Microsoft Windows 7, Vista, XP and 2000 using Microsoft Internet Explorer 6.0+ or Mozilla Firefox
Resolution: 704x576, 704x576, 352x288 and 176x144
Compression: MJPEG, MPEG-4 and H.264
Frame-rate: Up to 50fps in all resolutions and compression formats (25fps with wide dynamic range enabled)
Bandwidth control: Configurable bit-rate streaming
Day/night: Automatic infrared-cut filter for true day/night switching
Minimum illumination: Colour: 0.01 Lux. Monochrome: 0.001 Lux (F1.35)
Image stabilizer: Electronic image stabilisation
Video overlay: Time and text overlay
Imaging: Adjustable resolution, image quality and bit rate, flip and mirror, brightness, contrast, saturation, sharpness, white balance, exposure, AGC, AWB, AES, WDR Pro and Backlight compensation
Viewing, detection & recording
Auto-tracking: No
Auto-flip: No
Privacy masking: 3D privacy masking
Simultaneous users: Up to 10
Alarm detection: Video motion detection, audio detection and external input
External alarm inputs and outputs:3x Alarm input and 2x relay output
Alarm notifications: Record to SD/SDHC memoery card, upload images via FTP and email
Recording triggers: Alarm, schedule and continuous
On-camera recording: SD/SDHC Card Slot
Recording software included: ST7501 32-channel recording software
Compatible recording platforms (not included)
Software: Milestone XProtect, SecuritySpy (for Mac)
Network Video Recorders: QNAP range
Power: Power socket for 24V AC (adapter included)
Network: 10/100Mbps RJ-45 Ethernet conneciton with HPoE support
Alarm I/O: Terminal connections for 3x external inputs and 2x trigger outputs
Audio: 2x 3.5mm mini-jack connections for audio input and output
Dimensions: Camera: ø200mm x 270mm
Weight: 4.5Kg
Colour: White
Warranty: 2-Year manufacturer's warranty
Mounting methods: Wall-mountable using the included wall-mount bracket
Operating temperatures:24V: -40 to 55°C. HPoE: -10 to 55°C
Power consumption: 60W Max
Dynamic DNS: Yes
Protocols supported: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, SNMP and 802.1x
QoS: Yes
Security: Multi-level password protection, IP address filtering, HTTPS support and 802.1x authentication
System integration: SDK available
ONVIF compliant: Yes
