Vivotek | PT8133W
Vivotek PT8133W indoor 1MP pan/tilt IP camera with Wireless-N connectivity and integrated microphone
This product is discontinued, for alternatives please see Wisenet IP Cameras
Overview of the Vivotek PT8133W
The Vivotek PT8133W is a compact pan/tilt camera providing cost-effective surveillance indoors. Wi-Fi connectivity is provided with support for the 802.11N protocol for fast, reliable wireless connectivity. The camera also supports WPS connection for easy, no-configuration wireless connection to compatible routers.
Producing 1 megapixel resolution footage, the image captured by the camera is sharp and clear, while the 350° pan and 125° tilt let users monitor a large area. Additionally, audio events can be captured from the surrounding area using the camera's integrated microphone, alerting users to events happening off-screen.
The included Vivotek software allows a large scale surveillance system to be created consisting of up to 32 cameras at no additional cost. Support for MJPEG, MPEG4 and H.264 also provides flexibility when specifying image quality and bandwidth requirements for recording.
Key features & benefits of the Vivotek PT8133W network camera
- Create a cost effective surveillance solution with pan/tilt movement and bundled recording software
- Capture clear, crisp video with 1 megapixel resolution
- Quickly and easily install the camera on Wireless N networks
- Listen-in on events from around the camera with the integrated microphone
Typical applications
With Wi-Fi connectivity and pan/tilt movement, the PT8133W is ideal for a variety of open indoor environments, such as open-plan offices and studios, restaurants, bars, shops and garages.
Included accessories for the Vivotek PT8133W
- Warranty card
- Power adapter
- Software CD
- Antenna
- Mount kit and foot pads
- Screws
- Quick installation guide
Key technical features for the Vivotek PT8133W
Camera | |
Environment: | Indoor |
Type: | Pan-tilt-zoom IP camera |
Sensor: | 1/4" progressive CMOS sensor |
Lens: | Fixed 3.6mm (F1.8) lens with 58.39° horizontal viewing angle |
PTZ: | Pan: ±175°. Tilt: 120° |
Wireless: | 802.11b/g/n wireless connection with WPS encryption |
Audio: | 1-Way audio listen in with integrated microphone using GSM-AMR and G.711 compression |
Power: | 12V DC (adapter included) |
Processor/memory: | Multimedia SoC processor with 128MB flash and 128MB RAM |
Compatibility: | Microsoft Windows 7, Vista, XP or 2000 with Mozilla Firefox or Internet Explorer 7 or above |
Video | |
Resolution: | Multiple resolutions up to 1280x800 |
Compression: | H.264, MJPEG and MPEG-4 |
Frame-rate: | 30fps in all resolutions and compression formats |
Bandwidth control: | Adjustable resolution, quality and bitrate with image cropping to reduce bandwidth |
Day/night: | No |
Minimum illumination: | 0.3 Lux (F1.8, 50IRE) |
Video overlay: | Timestamp and text overlay |
Viewing, detection & recording | |
Auto-tracking: | No |
Auto-flip: | No |
Privacy masking: | Yes |
Simultaneous users: | 10 |
Alarm detection: | triple-window motion detection and external input |
Alarm notifications: | Event notification using HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server |
Recording triggers: | Video motion detection, manual, periodic and system boot |
On-camera recording: | No |
Recording software included: | Vivotek ST7501 32 channel recording software |
Compatible recording platforms (not included) | |
Software: | Milestone XProtect, SecuritySpy (for Mac) |
Network Video Recorders: | QNAP range |
Connections | |
Power: | DC jack for 12V DC power input |
Network: | 10/100Mbps RJ-45 Ethernet connection |
Wireless: | Wi-Fi antenna port with included antenna |
Other | |
Dimensions: | ø110mm x 120mm |
Weight: | 293g |
Colour: | Silver |
Warranty: | 2 year manufacturer's warranty |
Mounting methods: | Parapet or ceiling-mountable |
Operating temperatures: | 0-50°C |
Power consumption: | 5.1W |
Dynamic DNS: | Yes |
Protocols supported: | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, UDP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X |
QoS: | Yes |
System integration: | SDK available |
ONVIF compliant: | Yes |
