| MD8562D

Vivotek MD8562D rugged vandal-proof outdoor IP camera with wide dynamic range, MicroSD, HD1080p, M12 connection

Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Hurry! Only left

This product is discontinued, for alternatives please see Wisenet IP Cameras

Overview of the Vivotek MD8562D

The rugged Vivotek MD8562D IP camera is designed for use in tough environments. The camera is IP66 and IK10-rated, able to withstand harsh weather and vandalism, and is designed to be resistant to constant vibration, shock, high humidity and temperature changes, making it ideal for use on moving vehicles such as buses, trains, HGVs and taxis. The rugged M12 data connection also ensures that constant vibration does not interfere with the network connection.

With high contrast lighting expected in the camera's target environment, the MD8562D features Wide Dynamic Range technology, able to capture events in very bright and very dark locations simultaneously. The camera's wide viewing angle and HD1080p resolution capture detailed footage over a large area, minimising blind spots.

Able to record locally, the camera features MicroSD storage for reliable surveillance recording (card not included). The camera is also ONVIF-compliant, so can be easily integrated with many third-party network video recorders.

Please note: This camera does not come with a power supply. If you require one, please select one from the options above.

Key features & benefits of the Vivotek MD8562D

  • Full HD 1080p video provides crisp, clear detail
  • Wide-angle lens (110°) captures a large area, reducing the number of cameras required for large areas
  • Wide dynamic range software captures events in high contrast lighting
  • The IK10 and IP67-rated metal casing is vandal-proof and harsh weather resistant
  • EN50155 certified for use on railway rolling stock
  • Tampering detection alerts users if the view is moved or covered
  • 1-Way audio captures audible events alongside video
  • Rugged, M12 network connection
  • MicroSD card recording provides localised, reliable recording

Typical applications of the Vivotek MD8562D

The camera is designed for locations subject to high vibration and dust/water ingress, making it ideal for security on trucks, buses, trains and taxis. Additionally, the camera is ideal for monitoring of heavy machinery or production lines where vibration and dusty environments are expected.

Included accessories for the Vivotek MD8562D

  • Your choice of power supply (from above)
  • Software CD
  • Alignment sticker
  • Quick installation guide
  • Warranty card
  • Ground wire
  • Screws
  • Screwdriver
  • Moisture absorber
Back To Top

Key technical features for the Vivotek MD8562D

Environment: Moving vehicles / outdoors
Type: Compact fixed-dome
Sensor: 1/2.7" progressive scan CMOS sensor
Lens: Fixed 2.8mm (F2.0) lens with 110° horizontal viewing angle
Audio: 1-Way audio listen-in with GSM-AMR, AAC and G.711 compression
Power: 12V DC (adapter not included)
Compatibility: Microsoft Windows 7/Vista/XP/2000 with Internet Explorer 7 or above
Resolution: 1920x1080, 1600x1200, 1600x904, 1360x768, 1280x720, 800x600, 640x480, 640x360, 384x216, 320x240 and 176x144
Compression: H.264, MJPEG and MPEG-4
Frame-rate: 30fps in all resolutions and compression formats
Minimum illumination: 0.2 Lux
Video overlay: Timestamp and text
Imaging: Configurable brightness, contrast, saturation, sharpness, white balance and exposure, AGC, AWB, AES, WDR and backlight compensation
Viewing, detection & recording
Privacy masking: Yes
Simultaneous users: 10
Alarm detection: Video motion detection, system boot, recording notification and camera tampering detection
External alarm inputs and outputs:1x alarm input
Alarm notifications: Upload via FTP and email and recording to SD memory card
Recording triggers: Alarm, manual trigger, digital input and periodical trigger
On-camera recording: MicroSD memory card
Recording software included: ST7501 32-channel recording software
Compatible recording platforms (not included)
Software: Vivotek ST7501 (included), Milestone XProtect, Security Spy (for Mac)
Network Video Recorders: QNAP range
Network: Rugged M12 data connection
Power: DC mini-jack connection for 12V DC
Audio: 3.5mm mini-jack audio ports
I/O: Terminal block connections for I/O
Dimensions: 130mm x 107mm x 47mm
Weight: 450g
Colour: White
Warranty: 3 Year manufacturer's warranty
Mounting methods: Wall or ceiling mountable
Operating temperatures:-25 to 55°C (-13 to 131°F)
Power consumption: 4.3W (7.5W with heater)
Dynamic DNS: Yes
Protocols supported: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
QoS: Yes
ONVIF compliant: Yes
