Vivotek | IP8133
Vivotek IP8133 compact IP camera HD 720p with PIR sensor, LED light, PoE and 2-way audio
This product is discontinued, an alternative model is the Wisenet QNO-7082R
Overview of the Vivotek IP8133
The Vivotek IP8133 is an entry-level IP security camera designed for use in homes and offices, featuring an Integrated PIR sensor and LED lighting that can detect movement around the camera in complete darkness before illuminating the scene, providing a true 24-hour surveillance solution.
Detailed facial features can be captured as the camera produces video with HD 720p resolution, making it easy to identify people in view. Users can also listen-in on events around the camera using the built-in microphone or can challenge intruders through its integrated speaker.
With the included ST7501 recording software, users can build a powerful security system with multiple cameras at no additional cost. Additionally, the camera can alert on tampering, such as obscuring of the view or moving of the camera.
Please note: This camera does not come with a power supply. Should you require a Power over Ethernet midspan please add one from the options above.
Key features & benefits of the Vivotek IP8133
- The camera's compact casing is ideal for the home or small office
- HD 720p video produces clear, crisp video, ideal for facial identification
- Power the camera using an Ethernet connection for quick and easy installation
- Detect movement in complete darkness with the integrated PIR sensor
- Illuminate objects in dark locations or at night using the white light LEDs
- Hold two-way conversations with people in view using the built-in microphone and speaker
- Tamper detection software alerts users if the camera is covered, moved or obstructed
- Privacy button prevents unwanted monitoring at the push of a button
Typical applications of the Vivotek IP8133
The IP1833 is suited to indoor use in homes and office environments where connection to a local power source might be difficult.
Included accessories for the Vivotek IP8133
- Camera stand
- Software CD
- Warranty card
- Quick installation guide
- Screws
Key technical features for the Vivotek IP8133
Camera | |
Environment: | Indoors |
Type: | Fixed view |
Sensor: | 1/4" CMOS sensor |
Lens: | Fixed 3.45mm (F2.4) lens |
Audio: | 2-Way audio listen-in with integrated microphone and speaker |
Power: | 5V DC or Power over Ethernet (class 3) |
Video | |
Resolution: | Various resolutions between 1280x800 and 176x144 |
Compression: | H.264, JPEG and MPEG-4 |
Frame-rate: | MJPEG/H.264: 30fps in all resolutions. MPEG-4: 23fps in all resolutions |
Day/night: | No |
Minimum illumination: | 3.0 Lux @ F2.4 |
Video overlay: | Time stamp and text |
Imaging: | Brightness, contrast, saturation, sharpness, white balance, exposure, AGC, AWB, AES and backlight compensation |
Viewing, detection & recording | |
Privacy masking: | Yes |
Simultaneous users: | 10 |
Alarm detection: | Motion and tamper detection |
External alarm inputs and outputs: | 1x input, 1x output |
Alarm notifications: | Image transfer via FTP and email |
Recording triggers: | Manual, schedule and alarm |
Recording software included: | ST7501 32-channel recording software |
Compatible recording platforms (not included) | |
Software: | Milestone XProtect, Security Spy (for Mac) |
Network Video Recorders: | QNAP range |
Connections | |
Power: | Jack for 5V DC |
Network: | 10/100Mbps RJ-45 Ethernet connection |
Alarm I/O: | Screw terminals for input and output |
Audio: | Integrated microphone and speaker |
Other | |
Dimensions: | 133mm x 79mm x 94mm |
Weight: | 200g |
Colour: | White |
Warranty: | 2 Year manufacturer's warranty |
Mounting methods: | Wall, ceiling or desk-mountable using the included stand |
Operating temperatures: | 0 to 40°C (32 to 104°F) |
Power consumption: | 4.3W |
Dynamic DNS: | Yes |
Protocols supported: | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, and 802.1X |
QoS: | Yes |
Security: | Multi-level usernames and passwords |
System integration: | SDK available |
ONVIF compliant: | Yes |
