Vivotek | FE8171V
Vivotek FE8171V outdoor 3 megapixel hemispheric IP camera with vandal-proof housing, day/night, MicroSD, PoE
Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Overview of Vivotek FE8171V
This product is discontinued, an alternative model is the Panasonic i-PRO WV-S4556L
The FE8171V is Vivotek's first fixed dome IP camera with a fisheye lens, allowing the camera to monitor large areas using either its 180° panoramic view or a full 360° surround view with no blind spots. Using Vivotek's included ST7501 video management software switch between multiple fisheye and full panoramic views and focus on specific regions of interest (ROI) using its ultra-smooth ePTZ technology to adjust camera angles.
With a 3.1 megapixel sensor for superb image quality and a rugged vandal-resistant housing which allows the camera to be mounted in outdoor environments, the Vivotek FD8171V is ideal for surveillance of large, open areas in harsh weather.
The FE8171V has a removable infrared-cut filter, allowing it to continue monitoring at all times of the day and night, while an on-board MicroSD card slot provides an alternative recording solution (card not included).
Two-way audio support with a built-in microphone allows users to listen in to the camera's surroundings and connect external accessories such as speakers in order to issue warnings or instructions. The FD8171V is also PoE compliant, providing power and network over a single ethernet cable.
Please note: this camera does not come with a power supply, please select from above if required
Key features & benefits of Vivotek FE8171V
- Fisheye lens provides a 180° panoramic view (wall mount) or 360° surround view (ceiling mount)
- Panoramic and surround views produce an 8x wider field of view than a standard VGA camera
- Ultra-smooth ePTZ function allows quick and easy focus and zoom on regions of interest
- Day/night mode using an infrared-cut filter for 24 hour recording
- 3.1 megapixel resolution for superb image quality
- On-board MicroSD card slot for localised storage
- Robust vandal-resistant housing protects the camera against attempts to damage it and also against harsh weather conditions
Typical applications of Vivotek FE8171V
The Vivotek FE8171V can be mounted to ceilings and walls to help monitor a wide range of large open areas, including shopping centres, airports, train stations, open-plan offices, retail stores, reception areas and multi-storey car parks.
Accessories for Vivotek FE8171V
- Vivotek FE8171V IP camera
- Quick Installation Guide
- Software CD
- Alignment sticker
- Power adapter
- Warranty card
- Screwdriver
- Screws
Key technical features for Vivotek FE8171V
Camera | |
| Environment: | outdoor |
| Type: | fixed-dome hemispheric network camera |
| Sensor: | 1/2" CMOS sensor |
| Lens: | fixed 1.27mm (F2.8) board lens with removable infrared-cut filter |
| PTZ: | ePTZ |
| Audio: | GSM-AMR speech encoding (bit rate: 4.75 to 12.2 Kbps); MPEG-4 AAC audio encoding (bit rate: 16 to 128 Kbps); G.711 audio encoding (bit rate: 64 Kbps); built-in microphone, two-way audio and audio mute support |
| Power: | Power over Ethernet (IEEE 802.3af) Class 2; 12V DC |
| Compatibility: | Microsoft Windows 7/Vista/XP/2000; browser: Internet Explorer 6.x or above, Mozilla Firefox; mobile viewing: 3GPP; RealPlayer; Quicktime |
Video | |
| Resolution: | 2048x1536 (maximum); multiple resolutions between 1536 |
| Compression: | H.264, MPEG-4, MJPEG |
| Frame rate: | up to 15 fps @ 1536x1536 in all compression types |
| Bandwidth control: | multiple streaming |
| Day/night: | removable infrared-cut filter for day/night function |
| Minimum illumination: | colour: 1.17 lux @ F2.8; black & white: 0.2 lux @ F2.8 |
| Video overlay: | timestamp and text overlay |
| Imaging: | shutter time: 1/5 sec to 1/32000 sec; adjustable image size, quality and bit rate; flip and mirror; configurable brightness, contrast, saturation, sharpness, white balance and exposure; AGC, AWB, AES; WDR enhanced; automatic, manual or scheduled day/night mode; backlight compensation; privacy mask support |
Viewing, detection & recording | |
| Privacy masking: | yes |
| Simultaneous users: | live viewing for up to 10 users |
| Alarm detection: | event notification using HTTP, SMTP or FTP; tamper detection |
| External alarm inputs and outputs: | 1x D/I and 1x D/O for external sensor and alarm |
| Alarm notifications: | event notification using HTTP, SMTP or FTP, local recording of MP4 files |
| Recording triggers: | manual, alarm or schedule |
| On-camera recording: | MicroSD/SDHC/SDXC memory card slot (card not included) |
| Recording software included: | Vivotek ST7501 32-channel recording software |
Connections | |
| Power: | socket for DC connection |
| Network: | 10/100/1000Mbps RJ-45 Gigabit Ethernet connection with Power over Ethernet (IEEE 802.3af) support |
| Alarm I/O: | terminal block for audio input & output |
Compatible Recording Platforms (not included): | |
| Software: | Vivotek 32-channel ST7501 recording software (included); Milestone Xprotect |
| Network Video Recorders: | QNAP |
Other | |
| Dimensions: | ø145 x 52mm (DxH) |
| Weight: | 566g |
| Colour: | white |
| Warranty: | three year manufacturer's warranty |
| Mounting methods: | wall and ceiling mount |
| Operating temperatures: | -25°C to 50°C |
| Power consumption: | 3.84W (max) |
| Dynamic DNS: | yes |
| Protocols supported: | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
| QoS: | yes |
| Security: | Multi-level user access with password protection; IP address filtering; HTTPS encrypted data transmission; 802.1X port-based authentication for network protection |
| ONVIF compliant: | yes |
