Vivotek FD8371EV outdoor 3 megapixel IP camera with 20m infrared LEDs, HD 1080p (60 fps), PoE and SD card storage

Overview of the Vivotek FD8371EV

This product is discontinued, an alternative model is the Bosch FLEXIDOME IP Starlight 6000

High quality and cost-effective Vivotek FD8371EV network camera offering 3 megapixel video at 30 fps or HD 1080p at 60 fps, true day/night and built-in Smart infrared LED lights for night-vision up to 20m, motorised P-iris lens, 3D noise reduction, triple codec and two-way audio. Suitable for outdoor use in environments at risk of vandalism.

The Vivotek FD8371EV dome network camera delivers high quality video footage either in 3 megapixel resolution at 30 frames per second or HD 1080p at 60 frames per second, providing smooth monitoring ideal for demanding and fast-paced security applications. True day/night capability is enhanced by integrated LED lights providing up to 20m radiant distance for high quality monochrome image capture at night-time and in total darkness. The IP66 and IK10 rated casing protects the camera against bad weather and vandalism attempts, providing durable outdoor usability. Two-way audio capability is provided when a microphone and speaker are connected to the camera (not included), enabling sound to be recorded to complement video footage. Included Vivotek 32-channel recording software provides simple and cost-effective video management.

The FD8371EV IP camera has a motorised P-iris lens with built-in stepper motor for precise image capture, video is then enhanced further by wide dynamic range (WDR) technology, which captures detail in both bright and dark areas within a scene to ensure clear, unsaturated footage. In combination with 3D noise reduction, this enables the camera to deliver good performance in a diverse range of lighting conditions. Smart IR technology amends the infrared light intensity instantly depending on lighting environments to prevent overexposure and to provide high quality, optimised images at night-time.

Triple codec with H.264, Motion JPEG and MPEG-4 gives the user flexibility on compression method to suit different network and storage conditions. Power over Ethernet (PoE) support enables the FD8371EV to be powered through a single cable also feeding network connection for simplified cabling during installation. On-board recording onto a SD card (card not included) provides flexible storage management with data being available for transfer to a centralised recording device at low traffic times, avoiding network congestion.

Please note: this camera does not come with a power supply, please select a PoE midspan from the above drop down menu if required.

Key features & benefits

• 3 megapixel sensor producing high quality video at 30 frames per second, or HD 1080p video at 60 frames per second
• True day/night capability with 20m IR LEDs for enhanced night-vision and image capture in complete darkness
• Smart IR technology adjusts infrared light accordingly based on environmental lighting change
• Two-way audio support when a speaker and microphone are added (not included) for recording sound and speaking through camera
• IP66 and IK10 ratings mean the camera is protected against rain, dust and impact and is suitable for outdoor use in areas at risk of vandalism
• Motorised P-iris lens automatically focuses for easy installation and maintenance
• 3D noise reduction enables clear video to be captured in low light conditions and helps to reduce bandwidth usage
• Wide dynamic range (WDR) captures both bright and dark areas within a scene so detail is prominent in images
• Triple codec provides compression method flexibility with H.264, Motion JPEG and MPEG-4
• PoE support makes installing the FD8371EV quick and easy
• SD storage provides a useful backup solution in case of network failure to ensure data is uninterrupted

Compatible recording platforms

• Software:
  • Milestone XProtect (ONVIF)
• Network Video Recorders:
  • NUUO Network Video Recorders

Typical applications

The Vivotek FD8371EV network camera is ideal for advanced outdoor security applications that require critical surveillance in high frame rate and high quality such as casinos, hospitals, police stations and banks, where there is fast-paced activity and scenes are often very busy.

Accessories

Included:

• Wall mount bracket
• Sun shield
• Waterproof RJ45 Ethernet enclosure
• User manual
• Quick installation guide
• Installation wizard 2
• Vivotek ST7501 32-channel recording software
• Warranty card
• AV cable tape
• Bushing
• DC connector
• Double-sided tape
• Hex nut
• L-type hex key wrench
• Mounting plate
• Screws
• Alignment sticker/desiccant bag
• Waterproof connector

Optional (please select from above drop down menu if required):

• PoE midspan
• SD card
