Vivotek FD8361 outdoor 2 megapixel day/night fixed dome network camera with H.264, PoE, 20m night vision and 2-way audio

This product is discontinued, for alternatives please see Wisenet IP Cameras

Vivotek’s FD8361 is a 2-megapixel, fixed-dome IP camera which provides detailed, high quality footage with a weatherproof IP66-rated casing. The camera can function day and night using it's infrared-cut filter and integrated infrared LEDs, making it well suited to outdoor environments where 24-hour surveillance is required, such as shop fronts and train stations.

H.264 video compression optimises bandwidth usage while maintaining the quality of the image. The camera is also ONVIF compliant, meaning that it can be integrated easily with other third-party ONVIF compatible security hardware. Power over Ethernet also makes wiring very easy, with both power and data supplied through the Ethernet cable.

The camera also supports two-way audio, allowing the operator to verbally communicate with co-workers on-site or warn off intruders. Tamper Detection ensures the user is alerted instantly if the camera is blocked or moved, while recordings can be stored on-board SD memory card without any additional equipment.

Vivotek FD8361 - Key Benefits:

• Capture detailed, high quality footage with 6x more detail than a conventional IP camera
• View night-vision images for 24 hour surveillance
• Monitor footage in all weather conditions
• Reduce bandwidth usage without compromising image quality with H.264 video compression
• Receive an alert immediately if the camera is moved or obscured

Vivotek FD8361 - Key Features:

• 2 megapixel lens provides sharp, defined footage in resolutions up to 1600x1200 pixels
• Weatherproof IP66-rated housing protects against harsh weather conditions
• Infrared illuminators and removable IR-cut filter allow the camera to continue filming even in low-light
• ONVIF support means that the camera can be used with any ONVIF compatible product regardless of the manufacturer
• Tamper Detection alerts the operator if the camera is block or repositioned
• Supports two-way audio via SIP protocol
• Built-in microphone lets viewers listen to sound without any additional audio equipment
• Power over Ethernet makes installation easy and means the camera can be set up without the need for a nearby power source
• SD/SDHC card slot allows recordings to be stored on an on-board memory card (not included)
• H.264 compression optimises bandwidth efficiency
• Local recording of MP4 video files allow you to record without using external software
• ePTZ enables the camera to pan, tilt and zoom quickly and efficiently on any objects within the camera’s field of view
• Multi-Streaming means the video can be displayed in several streams at once, allowing frame rate, resolution and compression format to be adjusted
• Adaptive streaming offers dynamic frame rate control
• Privacy masks allow the operator to block certain areas from view
• Included 32 channel recording software stores footage to a Windows PC
• 3GPP mobile surveillance means the camera can be accessed through a 3G phone
• Backlight compensation captures definition of objects with a strong light source behind them

Vivotek FD8361 - Typical Applications:

• The Vivotek FD8361 is intended for use in open areas where high quality, 24 hour surveillance is required such as train stations, car parks or industrial sites.

Vivotek FD8361 - Key Technical Indicators:

• Compression format: H.264, MPEG-4 and MJPEG
• Shutter time: 1/5 - 1/40000 sec
• Lens: Varifocal 3-9mm (F1.2-F2.1) auto-iris lens with 31.7-93.0° horizontal viewing angle
• Sensor: 1/3.2" CMOS sensor in 1600x1200 resolution
• Max. frame rate: 30fps
• Max Resolutions: 1280x720 (H.264 and MPEG-4) 1600x1200 (MJPEG)
• Minimum light level required: 0 Lux (F1.2, IR LED on)
• Alarm Triggers: Triple-window video motion detection, Tamper detection
• Alarm Notification: Event notification using HTTP, SMTP or FTP
• Security: Multi-level user access with password protection, IP address filtering, HTTPS encrypted data transmission, 802.1X port-based authentication for network protection
• No. of simultaneous users: 10
• Protocols Supported: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, and 802.1X
• Power: 12V DC/24V AC, IEEE802.3af compliant Power-over-Ethernet
• Power Consumption: Max. 5.3W or 9.9W with heater, fan and IR illumination
• Operating Temperatures: -30-50°C (-22-122°F )
• Dimensions (Diameter x H): ø 170mm x 133mm
• Net Weight: 2.2 kg
• 3-axis mounting mechanism for flexible ceiling and wall installation

Vivotek FD8361 - Connections:

• 10/100 Mbps Ethernet, RJ-45
• External direct input
• External direct output
• External 3.5 mm mini-jack microphone input
• 3.5mm mini-jack audio output

Vivotek FD8361 - Accessories Included:

• Power adapter
• Screws
• Bottom base
• Quick installation guide
• Software CD
• Warranty card
• Clamp core
• Alignment sticker
