| VDC-3500P

Sanyo VDC-HD3500P, outdoor dome HD 1080p security camera with vandal-resistant casing, face detection, quad-streaming, PoE

Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Hurry! Only left

Overview of Sanyo VDC-HD3500P

This product is discontinued, an alternative model is the Axis P3265-LVE

The Sanyo VDC-HD3500P is a fixed dome IP security camera with a varifocal, megapixel-rated lens offering a highly-detailed HD 1080p image, making it suitable for mission-critical monitoring solutions in locations such as mass transit terminals. The VDC-HD3500P also incorporates Sanyo's Xacti HD-Pro/Optimum IP Pro twin-engine processing system, which processes network loads and images separately, significantly improving the performance of the camera.

As well as this, the VDC-HD3500P is capable of H.264 compression, reducing demands on your network's resources, and quad-streaming, which allows you to make the best use of your available bandwidth by watching live footage at one quality level while recording in several others. In addition, the camera is equipped with an infrared filter, allowing it to switch to a black-and-white infrared image in poor lighting conditions - even complete darkness - ensuring the camera provides a viable monitoring solution at all times (infrared lighting required). Alongside this, video analytics and face detection systems can intelligently trigger alarm events to automatically notify you when motion or faces are detected in the camera's field of view. The camera is also capable of bi-directional audio using its audio input/output, allowing you to communicate with the camera's surroundings.

The VDC-HD3500P is equipped with an IP66-rated, vandal-resistant casing that offers protection in adverse weather conditions and can withstand heavy impacts and attempts to tamper with the camera. An on-board SD card slot offers an integrated alarm recording and backup solution, and Power over Ethernet technology sends power and data to the camera through one cable, significantly reducing the amount of time required to install the camera. To further aid installers, the camera's focus assist features provides on-screen graphs and charts as visual aids to optimise the available image.

Please note: this camera does not come with a power supply. Please select if required.

Key features & benefits of Sanyo VDC-HD3500P

  • Full HD 1080p picture with H.264 compression, reducing the file size of video and images passing through your network without compromising their quality
  • Optimised megapixel-rated lens
  • IP66-rated, vandal-resistant casing deters vandals and protects the camera from adverse weather conditions
  • True infrared day/night filter provides a 24-hour monitoring solution, even in complete darkness (infrared lighting required)
  • Xacti HD-Pro/Optimum IP Pro twin-engine processing system processes images and network loads separately, significantly improving the speed and efficiency of the camera and its network connection
  • Face detection and video analytics intelligently monitor the camera's field of view, notifying you if required
  • Quad-streaming capability enables you to adjust the camera's output for a wide variety of simultaneous streams, useful for recording and monitoring at different resolutions
  • Bi-directional audio allows you to listen in to, and communicate with, the camera's surroundings
  • On-board SD card recording provides a local backup and alarm recording solution
  • Focus assist provides visual graphs on the monitoring screen to aid users and installers in optimising the image

Typical applications of Sanyo VDC-HD3500P

The Sanyo VDC-HD3500P is ideal for locations where a high-definition image is required, such as supermarkets and transit terminals

Accessories for Sanyo VDC-HD3500P


  • Video cable
  • Cushioning sheet
  • Hexagonal wrench
  • Connector
  • Pattern sheet
  • Setup CD
Back To Top

Key technical features for Sanyo VDC-HD3500P

Environment:outdoor (IP66-rated, vandal-resistant casing)
Type:fixed dome
Sensor:1/3" progressive scan CMOS
Lens:varifocal, 3 - 9 mm, F1.2 - 2.1; horizontal view angle - 34.6° - 102.2° (16:9), 31.7° - 93.0° (4:3); vertical view angle - 19.5° - 55.4° (16:9), 23.8° - 68.4° (4:3); focus assistant
Audio:G.711, bi-directional (full duplex)
Power:Power over Ethernet, AC, DC
Resolution:H.264/Motion JPEG: 1920x1080 to 320x180 (16:9), 2288x1712 to 320x240 (4:3)
Compression:H.264, Motion JPEG
Frame-rate:up to 25 fps at 1080p
Bandwidth control:quad-stream H.264/Motion JPEG
Day/night:true day/night - automatically removable infrared cut-filter
Minimum illumination:colour - 1.0 lux (F1.2, gain: high); B/W 0.1 lux (F1.2, gain: high)
Video overlay:16 characters
Analogue video out:composite out (for adjustment only)
Imaging:shutter speed - 1/10000 - 1/25; settings - backlight compensation, white balance, AGC, aperture compensation, DNR, cropping function
Viewing, detection & recording
Privacy masking:yes
Simultaneous users:up to 20
Alarm detection:built-in motion detection, face detection
Intelligent video:video analytics
External alarm inputs and outputs:2 inputs, 2 outputs
Alarm notifications:external output activation, video recording to local storage, indication on browser
Recording triggers:manual; automatic - motion, face detection
On-camera recording:SD/SDCH card slot (only for alarm/back-up; card is not included)
Recording software included:Auto-IP setup utility; HDC downloader/viewer
Compatible recording platforms (not included)
Software:Milestone XProtect, SecuritySpy (for Mac OSX)
Network Video Recorders:QNAP
Power:PoE (IEEE802.3af), 24 V AC, 12 V DC
Network:RJ-45 for 10BASE-T/100BASE-TX
Alarm I/O:2 inputs, 2 outputs
Audio:3.5 mm mic in/line out
Dimensions:⌀146 mm (5.75") x 94 mm (3.70")
Weight:800 g
Warranty:4 years (1 year on movable parts)
Mounting methods:Ceiling
Operating temperatures:-10°C - 50°C (14°F - 122°F); 90% humidity
Power consumption:6.8 W (with heater 20 W)
Security:BASIC authentication (ID/password), SSL supported (Image only), IP filtering
