| VS-2104PRO+

QNAP VioStor VS-2104 PRO+ Network Video Recorder with 4 channels and up to 8TB storage

This product is discontinued. An alternative model is available via our Video Management section
Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Hurry! Only left


This product is discontinued, for alternatives please see our video management section.

Overview of the QNAP VS-2104 PRO+ VioStor NVR

The QNAP VS-2104 PRO+ VioStor is an IP network video recorder with the capability of recording footage from up to four IP cameras connected via the internet or a Local Area Network. Using a web browser, users can easily monitor, record and playback footage from any location.

With additional QNAP servers, the maximum number of cameras connectable can be up to 120. A storage capacity of 8TB is provided by two hot-swap bays, while all recorded data is backed up via a RAID migration system. Data backup onto USB drives is also possible with a one-touch backup button.

With direct HDMI video output, and keyboard/mouse USB ports (sold separately), this video recorder can also function as a standalone unit. The embedded Linux operating system ensures stability and offers protection against malware.

Key features & benefits of the QNAP VS-2104 PRO+ VioStor NVR

  • Can record video from up to 4 IP cameras
  • Compatible with cameras up to 8 megapixels
  • Automatic data backup to USB with one-touch button
  • Up to 120 IP cameras can be monitored with additional QNAP NVR servers
  • Depending on the camera used, high quality video can be compressed in Motion-JPEG, MPEG-4, MxPEG and/or H.264
  • Intelligent video analytics enables users to search recordings for unforeseen activity, such as motion detection, missing objects, or if the camera is out of focus
  • Continuous, manual and scheduled recording modes
  • Up to 15 alarm schedules available for each camera
  • PTZ movements can be controlled, configured or preset within live monitor display
  • Video snapshots and digital zooms are available live and during playback
  • Audio recording from supported IP cameras
  • Live email and SMS notification on system errors and events
  • Real Time Streaming Protocol (RTSP) allow streaming to: Windows Media Player, Apple QuickTime, VLC player and other desktop media players
  • Recordings can be easily accessed through a web browser (Internet Explorer), network browser or FTP
  • Product is supported by an Uninterruptible Power Supply (UPS) for continued operation through any external power failures

Typical applications of the QNAP VS-2104 PRO+ VioStor NVR

The QNAP VS-2104 PRO+ VioStor NVR is suitable for application where high speed image rates are required along with a highly detailed image such as casinos, airports, train stations and prisons as well as schools, university campuses and retail environments.

Included accessories for the QNAP VS-2104 PRO+ VioStor NVR

  • Your choice of storage specification
  • Adapter and power cable
  • Installation CD-ROM
  • Ethernet cable x 2
  • Hard disk lock
  • Flat head screws
Back To Top


Key technical features for the QNAP VS-2104 PRO+ VioStor NVR

Video
Compression:Motion-JPEG, MPEG, MxPEG, H.264
Frame-rate:180 fps at full HD 1080p
Digital zoom:yes
Viewing, detection & recording
Processor:Dual-core Intel processor; 4GB memory; 180Mbps throughput
Multi-camera viewing:yes, 4
Simultaneous users:32
Intelligent video:yes
Recording triggers:motion detection, presence of foreign object, missing object, out of focus, camera occlusion
On-board recording:yes, SD card
Recording buffer:pre-recording 300 s, post-recording 300 s
Connections
USB drive backup:front - 1 x USB 3.0; back - 4 x USB 2.0; UPS
Power over Ethernet:2 x Gigabit RJ-45 Ethernet port
HDD capacity:2 x 3.5" HDD tray with SATA connections
Video output:1 x HDMI (full HD 1920 x 1080)
Other
Dimensions:102 mm (W) x 154 mm (H) x 218 mm (D)
Weight:2.5 kg net
Colour:Black
Operating temperatures:0°C (32 °F) to 40°C (104 °F)
Power:external power adaptor, 90 W; input: 100 - 240V
Power consumption:max 39.9W in operation
Protocols supported:HTTP, TCP/IP, SMTP, DCHP, StaticIP, DNS, DDNS, FTP, NTP, UPnP
Dual Gigabit LAN:failover; load-balancing; multi-IP setting
Security:Linux operating system protective against Spyware
