Pelco IX10-DN 1.3 Megapixel network camera with H.264, day/night switching and on-camera SD recording, PoE

This product is discontinued, an alternative model is the Axis P3265-LV

The Pelco IX10DN is a 1.3 megapixel camera with automatic day/night switching suitable for high resolution security monitoring of areas such as office, retail, education environments, warehouses or in any government or public building. The IX10DN is part of the Sarix range of Pelco Megapixel cameras, offering CCTV to the highest quality standards.

The Pelco IX10DN is a true day/night camera with a removable infrared cut filter allowing it to not only produce high quality colour images throughout the day but can also deliver infrared sensitive monochrome images in periods of low-light. Other features include H.264 compression ensuring high frame rates, on-camera recording and Power over Ethernet for ease of installation. A video output port can be used to help position and focus the lens at point of installation. Like all IP cameras offered by Network Webcams, the Pelco Sarix IX10DN 1.3 megapixel IP security camera has a built-in web server and can be viewed over a Local Area Network (LAN), Wide Area Network (WAN) or via the Internet as a streaming IP webcam.

Pelco Sarix IX10DN - Key benefits:

• Automatic day/night switching uses an IR cut-filter to produce true colour images during the day and infrared night vision images at night for 24-hour surveillance. Infrared illumination required for night vision (not supplied)
• 1.3 Megapixel sensor provides high resolution surveillance monitoring, ideal for identification of people or objects within a scene
• H.264 video compression offers bandwidth efficient video streaming reducing network load and storage requirements. For more information on H.264 video compression

Pelco Sarix IX10DN - Key features:

• Dual streaming MJPEG and H.264 video compression offering bandwidth efficient monitoring and high compatibility
• True day-night switching for 24-hour video surveillance
• Maximum resolution: 1280 x 1024 pixels (1.3 megapixel)
• Frame rate of up to 30 frames per second
• Auto back-focus ensures delivery of clear, sharp, perfectly focused images 24-hours a day
• Power over Ethernet IEEE802.3af for a quick, easy and cost-effective installation
• On-camera recording solution using mini SD memory cards, ideal for monitoring in locations without a network connection
• Network protocols SSL allow data to be passed encrypted for added security, SSH for remote login and QoS for priority or guarantee data flow
• Video setup jack eliminates the need to use a laptop when positioning/focussing the camera lens

Pelco Sarix IX10DN - Typical applications:

• Megapixel IP CCTV security camera for monitoring a wide range of indoor locations in high detail such as office space, shops, hotels, restaurants, factories, schools, banks, universities and other public and commercial buildings and facilities

Pelco Sarix IX10DN - Key technical indicators:

• Video compression: Dual streaming MJPEG, H.264 Base Profile
• Sensor: 1/3 inch CMOS progressive scan sensor
• Lens: 2.8-8mm vari-focal, DC-iris, cs-mount, horizontal viewing angle: 89° (wide) - 32° (tele) at 4:3 aspect
• Supported resolutions: 1280x1024, 1280x960, 1280x720, 800x600, 704x576, 704x480, 640x512, 640x480, 640x352, 480x368, 480x272, 352x288, 352x240, 320x256, 320x240, 320x176
• Frame rate: Up to 30 fps (at 1280x720 or below), 20 fps (at 1280x960 or above)
• Minimum illumination: 0.25 lux (0 lux with infrared lighting, not supplied)
• Wide Dynamic Range: 60dB
• Removable IR cut-filter for day/night switching
• Mini SD card slot for alarm capture
• Supported protocols: TCP/IP, UDP/IP (Unicast, Multicast, IGMP), UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, SNMP, QoS, HTTP, HTTPS, LDAP (client), SSH, SSL, SMTP, FTP, MDNS (Bonjour)
• Number of simultaneous users: 20, unlimited users using multicast MPEG-4 or H.264
• Security: Password protection
• Power: 24VAC or Power over Ethernet (PoE Class 3)
• Consumption: less than 6W
• Weight: 0.5kg (without lens)
• Operating temperatures: -10°C to 50°C (14°F to 122°F)
• Dimensions: (HxWxD) 75.9mm x 79.2mm x 136.7mm

Pelco Sarix IX10DN - Connections:

• Network: Ethernet Cat5, RJ-45 connector for 100Base-TX
• Mini SD memory card slot
• 1x Alarm input, 1x alarm output
• Video output: 2.5mm jack service connector, provides NTSC/PAL video output

Pelco Sarix IX10DN - Accessories included:

• Pelco Sarix IX10DN IP camera (IX10DN)
• Varifocal megapixel lens, 2.8-8mm, auto-iris, CS-mount (13M2.8-8)
• Internal wall/ceiling mount bracket (WBCD14a)
• Additional items you may have chosen (from selections above)
• 1x Ferrite (Class B compliance)
• 1x 6-pin connector
• 1x IX Series quick start guide
• 1x Resource disc
