| IPR-614ES

Lilin IPR-614ES Outdoor IP security camera, HD 720p, infra red night-vision with 25m range, H.264 and HPoE support

Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Hurry! Only left

This product is discontinued, for alterative models please see Wisenet IP Cameras

Overview of Lilin IPR-614ES

The Lilin IPR-614ES is an outdoor IP CCTV camera designed for operating in the harshest of weather conditions. The camera provides a full HD 720p image, and an IP66-rated aluminium casing offers protection from acts of vandalism.

Available with a choice of a 4.3mm or 6mm lens, the camera is also equipped with built-in infra-red LEDs, providing effective infra-red illumination up to a distance of 25m. The IPR-614ES also has a built-in infra red filter, which switches from HD colour images to black and white images at night, ensuring clear video footage even in total darkness and allowing the camera to monitor around the clock.

The IPR-614ES has a range of menus to allow configuration for a number of handheld devices and smartphones, including Blackberry, iPad, iPhone and Android devices. Up to 8 users can view the camera at the same time and up to 10 user accounts can be set up. The camera also comes with free CMX recording software with support for up to 72 cameras, offering an all-round security solution.

The camera is equipped with High Power over Ethernet, meaning that only one cable is required to provide the camera with both power and data, helping to reduce costs and installation time. Images can be sent by e-mail and uploaded via FTP when motion detection is triggered, providing an effective security solution. Supplied with a cable managed bracket as standard, cables are hidden and cannot be tampered with.

Please note: this camera does not come with a power supply. Please select a power supply or PoE midspan from above drop-down if required

Key features & benefits of Lilin IPR-614ES

  • Day/night functionality with integrated infra red LEDs and automatic infra red cut filter produces full colour images in daytime and black and white images at night, ideal for 24-hour surveillance
  • 720p HD resolution provides clear video footage even in the busiest of environments
  • High Power over Ethernet provides power to and video data from the camera using only one cable, helping to save on cost and installation time
  • Robust aluminium housing for outdoor use providing protection against potential vandalism
  • Free CMX recording software

Typical applications of Lilin IPR-614ES

The IPR-614ESX makes an ideal choice as a day/night surveillance solution for areas such as university campuses and outdoor car parks, where round-the-clock CCTV is required and the camera could be subjected to harsh weather conditions.

Accessories for Lilin IPR-614ES


  • Cable managed bracket
  • Installation guide
  • CD with installation tools
  • NVR Management Software and user's manual
  • Screws and raw plugs for wall mounting
  • CMX recording and management software
Back To Top

Key technical features for Lilin IPR-614ES

Environment: outdoor
Type: fixed view with built-in infra red LEDs
Sensor: 1/4" progressive scan CMOS, 1280(H) x 800(V) = 1,024,000 (effective pixel)
Lens: Choice between 4.3mm fixed lens (horizontal viewing angle 49.8°) and 6mm fixed lens (horizontal viewing angle 35.8°), iris F1.8
Power: 24V AC or High Power over Ethernet (IEEE802.3at compliant)
Processor/memory: Intel Pentium 4 1.8GHz or above with 1GB or above, Independent Display Card
Compatibility: Windows 2000, Windows XP, Windows Vista, Windows 7, browser: Windows Internet Explorer 5.0 or above
Resolution: 720P (1280 x 768) / VGA (640 x 384) / CIF (320 x 192)
Compression: H.264/AVC, Motion JPEG
Frame-rate: H.264: up to 20 fps at 720P, MJPEG: up to 10 fps at 720P
Bandwidth control: bit rate 128Kbps to 5Mbps, streaming, RTSP: RTP/HTTP, RTP/TCP, RTP/UDP
Day/night: switchable day/night filter with intregrated infra red LED illumination (850nm), up to 25 metre range at a 20° spread
Minimum illumination: colour: 3 lux at F1.8; mono: 0.6 lux at F1.8; 0 lux (complete darkness) with infra red illumination on
Imaging: white balance: auto / tungsten / indoor / fluorescents1 / fluorescents2 / outdoor1 / outdoor2; back light compensation: auto; electronic shutter: 1/30(25)S ~ 1/20,000S
Viewing, detection & recording
Access: via local network, internet, iPhone and Andriod support
Simultaneous users: 8
Zoom: digital only
Alarm detection: events triggered by built-in motion detection
Alarm notifications: image upload over FTP and e-mail by motion detection
Recording triggers: motion detection
Compatible recording platforms (not included)
Software:Merit Lilin CMX recording software (included), Milestone XProtect
Power: socket for 24V AC
Network: 10/100Mbps Base-T, RJ-45 Ethernet connection, High Power over Ethernet (HPOE) IEEE 802.3at
Dimensions: body: 100mm(w) x 104mm(h) x 265mm(d)
Weight: 1600g
Colour: Silver/grey
Warranty: 3 year manufacturer warranty
Mounting methods: wall mount
Operating temperatures:-10 to 50°C (14 to 122°F)
Power consumption: 24V AC, 12W / HPoE+, 13.5W
Dynamic DNS: yes
Protocols supported: IP, TCP, UDP, HTTP, SMTP, ESMTP, NTP, DDNS, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet
Security: Base64 HTTP encryption, multiple user access levels with password protection
ONVIF compliant: Yes
