| IQA31NE-B5

IQeye Alliance-pro IQA31NE-B5 outdoor IP camera with HD720p, Lightgrabber, 2-way audio

Free delivery on mainland UK and most EU countries Check delivery charges to where you are.
Hurry! Only left

This product is discontinued, for alterative models please see LILIN IP Cameras

Overview of IQeye Alliance-pro IQA31NE-B5

With a robust vandal-resistant housing to protect against weather and tampering, the IQeye Alliance-pro IQA31NE-B5 is an IP camera well suited to outdoor surveillance. Powered using less than 4W through its Power over Ethernet connection, the IQA31NE-B5 provides a cost-effective and environmentally friendly security solution.

A 1 megapixel sensor allows the camera to capture video in clear, crisp HD720p resolution, making the IQA31NE-B5 ideal for monitoring at-risk areas which require high visual detail. A built-in infrared-cut filter switches from full colour to black and white video, which when used with infrared lighting (sold separately) provides a round-the-clock surveillance solution. IQinVision's built-in Lightgrabber feature increases camera sensitivity in response to low-light conditions to ensure the best possible image is captured.

The camera has 2-way audio compatibility, with connection for a microphone and speakers in order to provide a means of communication between control rooms and those in the camera's field of view - ideal for issuing instructions or warnings.

Please note: this camera does not come with a power supply. Please select if required.

Key features & benefits of IQeye Alliance-pro IQA31NE-B5

  • HD720p resolution at up to 60fps provides clear, crisp video footage
  • Day/night mode using an infrared-cut filter to switch between full colour and monochrome to allow for constant monitoring (infrared light source required)
  • Vandal-resistant housing helps to protect the camera against attempts at vandalism
  • Lightgrabber II feature increases camera sensitivity in low-light conditions to help capture the best possible image
  • Low-power Power over Ethernet (PoE) connection allows power and data to reach the camera over a single cable, helping to save on wiring. The camera can operate using less than 4W of power when used with PoE, providing an eco-friendly security solution

Typical applications of IQeye Alliance-pro IQA31NE-B5

The IQEye IQA31NE-B5 can be used to monitor a wide range of outdoor locations, including those which may be prone to vandalism, including train stations, school grounds, loading bays, shop entrances and public parkways.

Accessories for IQeye Alliance-pro IQA31NE-B5


  • IQeye Alliance-pro IQA31NE-B5 outdoor IP camera (IQA31NE-B5)
  • B5 Wide Angle Lens
  • Installation CD
  • Back Box (IQAE-BOX)
  • Wall Mount Adaptor (IQA-WM)
  • Pole Mount Adaptor (IQ800-PMA)
Back To Top
Type:dome camera
Sensor:1 megapixel 1/3" CMOS sensor
Lens:B5 wide angle lens (3-13mm); 1/3" M14, F1.4; viewing angle: 27° - 89°
Audio:two-way audio using G.711 compression (PCM 8 kHz)
Power:Power over Ethernet (802.3af) Class 1
Resolution:1280x720 (maximum)
Compression:H.264 and MJPEG
Frame-rate:up to 60 fps
Bandwidth control:simultaneous H.264 & MJPEG streaming
Day/night:yes (IR range: 800–940 nm)
Minimum illumination:colour: 0.1 lux; black and white: < 0.05 lux
Imaging:shutter speed: 1/12000; saturation, contrast, brightness, sharpness, Lightgrabber II
Viewing, detection & recording
Simultaneous users:up to 8 local or remote users using IQaccess application
Alarm detection:motion detection (user configurable)
External alarm inputs and outputs:1 input, 1 output
Recording triggers:motion detection, external device
On-camera recording:Micro SD (Class 6+)
Recording software included:on-camera IQaccess application
Compatible recording platforms (not included)
Software:Milestone XProtect, IQeye IQrecorder
Power:Power over Ethernet (802.3af) Class 1; 24V AC, 12-24V DC
Network:RJ45 10Base-T/100Base-TX Ethernet with PoE support
Physical I/O:4-pin push-in terminal block for 1 input, 1 output
Audio:terminal block for Mic/Line in, Line out; terminal block for speaker output
Dimensions:146.2mm(W) x 137.6mm(H)
Colour:white with black dome
Warranty:5 year manufacturer warranty
Mounting methods:ceiling mount
Operating temperatures:-20 – 50°C
Power consumption: < 3.4W (typical)
Protocols supported:TCP/IP, HTTP, HTTPS, DHCP, UDP, RTP, RTSP, DNS, ARP, ICMP, NTP, UPnP, ZeroConf, APIPA, UDP multicast, SNMP, FTP, SMTP, Telnet, CIFS
Security:secure multi-level password protection
System integration:ONVIF, PSIA, IQfinder, IQmanager, IQsentry, IQevent, Direct-to-Storage
ONVIF compliant:yes
