IQeye IQA13SI Alliance 3.0MP IP camera Digital PTZ PoE 2048x1536 indoor

This product is discontinued, for alterative models please see Wisenet IP Cameras

The IQA13SI network camera is a 3.0 megapixel resolution camera delivering images at a maximum size of 2560x1920 for better identification of people or objects in a scene. With its vandal resistant casing and compact, low-profile design the camera offers unobtrusive IP CCTV surveillance in a wide range of indoor environments.

Easy to install, the IQA13SI is Power over Ethernet compliant. This allows the camera to be installed using a single Ethernet cable which supplies both the data and power connections. The unique 3-axis pivoting mechanism allows free position of the lens and the auxiliary analogue output helps with lens positioning and focus.

Its hybrid design allows the cameras to not only operate across digital IP networks but also integrate with analogue CCTV systems. This allows you to protect your initial analogue investment while you migrate to a fully IP-based solution. Like all IP cameras offered by Network Webcams, the IQA13SI network security camera has a built-in web server and can be viewed over a Local Area Network (LAN), Wide Area Network (WAN) or via the Internet as a streaming IP webcam.

Important: This camera does not include a power supply unless you have selected one from the options above.

An outdoor version is available: IQeye IQA13SE outdoor ready fixed dome network camera

IQeye IQA13SI - Key benefits:

• Megapixel resolution provides high-quality, detailed images for better identification of people or objects in a scene
• A fixed dome design provides an unobtrusive installation resulting in non-invasive monitoring
• Vandal-resistant solid aluminium casing with rugged polycarbonate bubble allows you to place the camera in exposed areas
• Easy to install. Using Power over Ethernet (PoE IEEE802.3af) the camera can be installed using a single Ethernet cable resulting in a quick, easy and cost effective installation

IQeye IQA13SI - Key features:

• Solid aluminium construction and impact-resistant dome provides protection against vandalism or attack
• 3.0 Megapixel resolution provides maximum image size of 2048 x 1536 pixels
• Frame rate of up to 12fps
• MJPEG video provides maximum compatibility
• Easy to install with Power over Ethernet (IEEE802.3af) support. Power is injected into a standard Ethernet cable and this provides the power and data connection to the camera allowing it to be installed in virtually any location, even in places that have no means of conventional power
• Unique 3-way pivoting lens mechanism allows for simple lens adjustment and positioning
• Two analogue video outputs provide an output for engineers for easy lens positioning and a permanent output for display of images on a public viewing monitor
• Record directly to the camera using an SD HC memory card (SD HC memory card not supplied)
• LIGHTGRABBER II low-light feature provides usable images in lighting conditions as low as 0.2 lux
• Multi-camera viewing allows up to 9 simultaneous cameras to be displayed on a single screen without the need for additional software
• Privacy masking allows sensitive areas of a scene to be masked from view
• Digital image cropping allows images to be cropped/reduced in size to optimise bandwidth, remove sensitive areas or simply to focus on a specific point
• Digital pan-tilt-zoom operation means you can zoom into the image and pan/tilt with no moving parts. No moving parts means that people in the vicinity cannot tell where the camera is looking and also greatly reduces wear and tear on the camera
• Comprehensive set of image and exposure settings. Fine tune your images to your exact requirements
• Multi-zone motion detection with exclusion zone masking and sensitivity adjustment
• Alarm management tools allow comprehensive triggers to be set in the camera which can notify users of triggered events by email with image attachment or send a series of images to an FTP server
• 64 independent streams using IPcameo, each with their own resolution, sub-stream frame-rate and compression settings
• Recording software can be installed as an option to the camera which provides a full on-camera recording and playback solution without the need for any additional recording equipment

IQeye IQA13SI - Typical applications:

• Compact dome design for unobtrusive IP CCTV security monitoring with high-resolution megapixel quality and vandal-resistant casing. Ideal for indoor public areas such as shopping centres and precincts, police stations, prisons, casinos or any other indoor public space or building

IQeye IQA13SI - Key technical indicators:

• Compression format: MJPEG
• Image sensor: 1/3 inch progressive scan CMOS imaging sensor with dichroic infrared mirror
• Resolution: Maximum 2048x1536 (3.0 megapixel)
• Frame-rate: Up to 12fps
• Min. illumination: 0.2 lux using LIGHTGRABBER II
• Lens: 2.5-7mm varifocal lens, manual iris, F1.4. Horizontal viewing angle to be confirmed
• Power over Ethernet (PoE) 48V IEEE802.3af compliant
• Protocols supported: IP, TCP, UDP, ICMP, ARP, FTP, SMTP, DHCP, HTTP, RARP, BOOTP, SNMP, Telnet, TFTP
• Security: Security comprises of multi level password protection
• Construction: Vandal resistant aluminium body with impact resistant polycarbonate dome
• Operating temperatures: 0°C to 40°C (32°F to 104°F)
• Dimensions: (Diameter x Height) 145 x 97mm
• Weight: 0.78kg

IQeye IQA13SI - Connections:

• Network: RJ45 Ethernet connector (IEEE 802.3af PoE compliant)
• Analogue video out: 75ohm BNC connector
• Analogue installation setup port: RCA female
• SD Media Slot
• Alarm I/O: 4-pin screw terminal (pig tail), 1 input, 1 output
• Power supply: 2-pin captive terminal screw terminal (pig tail) No PSU supplied

IQeye IQA13SI - Accessories included:

• B4 Lens 2.5mm to 7mm Varifocal
• CD with installation guide and manual

Additional items you may want to order with this camera:

• IQrecorder. A full recording and playback solution built into the camera. No requirement for a PC to be present
