IQeye 805 Sentinel 5.0MP IP camera Digital PTZ PoE 2560x1920

This product is discontinued, for alternatives please see Outdoor IP Cameras with Pan Tilt Zoom

The IQ 805 Sentinel Series is an all-weather integrated 5.0 megapixel network camera and IP66 rated external housing solution, suitable for a wide range of security surveillance and monitoring applications. The integrated housing is vandal and tamper resistant and the complete system can be powered entirely using Power over Ethernet, simplifying installation. The IQ 805 can deliver 5.0 megapixel images giving a maximum resolution of 2560 x 1920 pixels at a frame-rate of up to 10 images per second. Advanced features include a comprehensive alarm management system allowing image transfer by email or FTP. Alarms can be triggered using video motion detection, sensor input or on a time-lapse basis. Digital pan-tilt-zoom provides unobtrusive close-up monitoring with no moving parts. Like all IP cameras offered on www.networkwebcams.co.uk, the IQeye 805 Sentinel Series IP camera has a built-in web server and can be viewed over a Local Area Network (LAN), Wide Area Network (WAN) or via the Internet as a streaming IP webcam.

Important: This camera does not include a power supply unless you have selected one from the two options above.

Network Webcams offers trade discounts to resellers on all IQeye cameras.

An indoor version is available: IQ705 5.0 Megapixel IP camera

IQeye 805 - Key benefits:

• Integrated camera and all-weather IP66 rated enclosure, vandal and tamper resistant, designed for both indoor and outdoor use
• Power-over-Ethernet (PoE) built-in compatibility for the complete camera and housing system enables easy installation in virtually any location (no conventional power required at point of installation)
• 5.0 Megapixel sensor provides high-quality images
• Digital pan-tilt-zoom for unobtrusive, close up monitoring. No moving parts means it’s impossible to detect where the camera is pointing and also represents less wear and tear on the camera
• Simultaneous high resolution and low bandwidth streams allowing remote viewing of live video whilst recording crisp megapixel images

IQeye 805 - Key features:

• Integrated camera and enclosure can be powered entirely using Power over Ethernet (PoE), simplifying installation
• IP66 rated, vandal and tamper resistant enclosure, designed for indoor and outdoor installations and suitable for exposed areas prone to vandalism
• Pivoting arm can be wall, ceiling or parapet fixed. Arm extents 360° pan – 180° tilt
• Built-in motion detection with 8 motion zones that can be independently configured for sensitivity
• Digital pan-tilt-zoom (PTZ) allowing for non-invasive monitoring
• Digital PTZ can be used by multiple users simultaneously and works with both live and recorded images
• Event-triggered alarm via e-mail and FTP and/or an external alarm device
• Automatic pre-/post-alarm recording
• Display of live video from multiple cameras on a single browser page
• Automatic white balance, shutter, exposure and gain control
• Night mode setting (slowing down shutter speed by 1/2 or 1/4)
• Digital image cropping
• Backlight compensation: User-configurable exposure window with include and exclude options
• Network security using multi-level password protection

IQeye 805 - Typical applications:

• Monitoring of offices, shops, hotels, factories, schools, banks, universities, car parks, industrial and commercial property, train/bus station terminals and other public and commercial spaces and facilities
• Use this item as a webcam – Streamdays offers an off-the-shelf solution for you

IQeye 805 - Key technical indicators:

• Compression format: JPEG and Motion JPEG
• Image sensor: 5.0 Megapixel 1/2" CMOS, progressive scan with dichroic mirror
• Resolution: maximum 2560(H) x 1920(V) pixels
• Frame rate: up to 10 frames per second (at 2560x1920)
• Minimum light level required: 0.3 lux
• Number of simultaneous users: dependent on bandwidth (3-5)
• Lens: f1.8, manual iris, varifocal 4.5-13mm, horizontal viewing angle 61° - 27° IR corrected
• Protocols supported: IP, TCP, UDP, ICMP, ARP, FTP, SMTP, DHCP, HTTP, RARP, BOOTP, SNMP, Telnet and TFTP
• Dimensions HxWxD (mm): Camera Housing (incl. sunshield): 92(H) x 132(W) x 244(D) Overall: 243(H) x 132(W) x 390(D)

IQeye 805 - Connections:

• Network: Ethernet 10/100, RJ-45
• Punch-down terminal for Cat5 cable
• Power: 12-24VDC, 24VAC or IEEE802.3af Power over Ethernet (no power adapter supplied)
• Analogue Video Output - RCA connection. Used for adjusting focus and depth of field (IQfocus)
• I/O screw terminal: direct power for 12-24VDC or 24VAC, 1 alarm output + 1 alarm input

IQeye 805 - Accessories included:

• V7 Lens Wide-Angle 4.5-13mm focal length
• Allen Wrench
• Wall Mount Template
• Punch down tool
• CD-ROM with installation tools and documentation

Additional items you may want to order with this camera:

• Milestone recording software, or
• IQeye IQrecorder on-camera recording software allowing On Camera Recording
