Hanwha Vision (Wisenet) | TNO-C8083E
Hanwha Vision TNO-C8083E explosion-proof lightweight and compact varifocal bullet IP camera, SUS136L stainless steel, IP66, IK10, Zone 1 ATEX certified with 5MP resolution, WDR, AI-enhanced analytics and PoE support
Free delivery on mainland UK and most EU countries. Check delivery charges to where you are.
Engineered and certified for safe use in explosive atmospheres, this compact and lightweight ATEX-rated bullet IP camera delivers excellent video quality in 5MP resolution, with AI analytics for early warning detection and classification of objects.
- 5MP image sensor for 2592x1944 video resolution
- 3.2~10.2mm motorised varifocal lens for 29°~95° horizontal viewing angle
- ATEX-certified for Zone 1 / Division 1 areas at risk of explosion
- WDR optimises scenes with shadows and contrasting lighting
- Advanced AI analytics for reliable object detection and classification
- Hanwha Vision 5-year warranty, firmware support until 5 years after EOL
Overview of the Hanwha Vision TNO-C8083E compact ATEX camera
- ATEX-certified for use in potentially explosive and flammable atmospheres
- Captures crisp and smooth full HD video with a horizontal viewing angle of 29° ~ 95°
- Excellent low light performance with WDR for balancing contrasting lighting
- Accurately detect and classify objects with AI-driven video analytics
- Extremely robust yet compact and lightweight for easy installation
Featuring a compact bullet form factor, this lightweight high-performance IP camera is fully ATEX certified for use in potentially explosive Zone 1 / Division 1 environments where safety and compliance are paramount. The stainless steel (SUS136L) housing ensures any potential sources of ignition due to malfunctions are contained within the casing, which is IP66 and IK10-rated for effective protection against wet weather conditions and harsh cleaning chemicals. Despite its extremely robust construction, this cost-effective device is one of the lightest ATEX-certified cameras available, weighing just 4.78kg.
The device is equipped with a 5MP image sensor and 3.2x motorised varifocal lens which captures smooth and detailed video up to 30fps, ideal for monitoring areas such as production lines with high levels of movement. Scenes suffering from contrasting light and shadows are balanced with WDR to ensure important details aren't missed. PoE with 1/2" cable gland type facilitates easy installation with reduced costs from a single cable, and additional mounting accessories allows the device to be securely installed directly to walls or on poles.
Video Analytics
Configure alerts to trigger in your VMS upon detection of analytics events, such as motion detection, virtual line crossing and loitering warning. The advanced AI-engine enhances the classification of objects by identifying persons and vehicles, but also determining specific types such as cars, buses, trucks and bikes. These objects can be visualised on screen with colour coded bounding boxes, making it easier to keep an eye on events as they unfold. Additionally, false alarms are minimised thanks to this granular level of detection and classification, only alerting users to incidents worthy of investigation.
Recording and Video Management
Available recording and video management options for this camera:
Example Use Cases
- General perimeter and zone protection - Early detection of humans or vehicles, configure alerts upon unexpected behaviour, prevent access to restricted areas
- Factories / power plants - detect employees and members of the public entering hazardous zones with virtual line crossing, loitering detection prevents individuals from spending too much time in specified zones, monitor machinery to ensure optimal performance and aid predictive maintenance, enforce PPE compliancy
- Oil rigs - improve employee safety through notifications of objects crossing restricted lines, early warning detection of potential developing incidents
Accessories included
- Camera
- Installation guide
- Hex L wrenches
- Mounting hex bolt set
- Tapping screws
- Mounting wrench bolts
- Copper tube terminal
- Copper tube fixing wrench bolts
Key technical features of the Hanwha Vision TNO-C8083E
Camera |
|
| Environment: | ATEX-certified, Zone / Division 1 |
| Type: | bullet camera |
| Sensor: | 1/2.8" 5MP CMOS |
| Lens: | Focal Length (Zoom Ratio): 3.2~10.2mm(3.2x) motorized varifocal
Max. Aperture Ratio: F1.6(Wide)~F3.1(Tele) Angular Field of View: H: 95°(Wide)~29°(Tele) V: 69°(Wide)~21°(Tele) D: 126°(Wide)~36°(Tele) Min. Object Distance: 1.2m (3.93ft) Focus Control: Simple focus Lens Type: DC auto iris(IR corrected) |
| PTZ: | digital PTZ support |
| Audio: | N/A |
| Power: | PoE: Max 9.50W, typical 5.30W |
Imaging |
|
| Resolution: | 2592x1944, 2560x1440, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Frame rate: | H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps(@5MP Max. 5fps) |
| Video streaming: | Unicast(20 users) / Multicast
Multiple streaming(Up to 5profiles) |
| Day/night: | Auto(ICR) |
| Minimum illumination: | Colour: 0.07Lux (F1.6, 1/30sec)
B/W: 0.007Lux (F1.6, 1/30sec, 30IRE) |
Analytics |
|
| Application Programming Interface: | ONVIF Profile S/T/M
SUNAPI(HTTP API) |
| Event triggers: | Classified object type: Person/Vehicle
Attributes: Vehicle(Type:car/bus/truck/motorcycle/bicycle) Support DetectionShot Analytics events based on AI engine - Motion detection*, Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit) Based on AI engine - People/Vehicle counting, Queue management, Heatmap Analytics events - Motion detection, Defocus detection, Tampering, Virtual area(Appear/Disappear) * Some of the video analytics only works with people and vehicle detection |
| Alarm triggers: | Analytics, Network disconnect |
| Event action: | File upload via FTP and e-mail
Notification via e-mail Handover(PTZ preset, Send message by HTTP/HTTPS/TCP) |
Video Management |
|
| On-camera recording: | N/A |
| Network video recorders: | Hanwha Vision NVRs, Milestone Husky NVRs, ONVIF support for 3rd party NVRs |
| Video Management Software: | Wisenet Viewer Application, Wisenet WAVE, Milestone XProtect |
| Cloud: | Eagle Eye Networks |
General |
|
| Dimensions: | ø110.5 x 316.2mm(ø4.35x12.44") |
| Weight: | 4770g(10.51 Ib) |
| Casing: | IP66/IP67-, NEMA 4X-, and IK10-rated
Colour: Silver Material: Stainless (SUS316L) |
| Certifications: | CE, KC, IP66, IK10,
ATEX,
II 2 G Ex db IIC T6 Gb II 2 D Ex tb IIIC T80°C Db IECEx, Ex db IIC T6 Gb Ex tb IIIC T80°C Db |
| Operating temperatures: | -30°C~+55°C(-22°F ~ +131°F) / 0~95% RH(non-condensing)
* Start up should be done at above -30°C |
| Warranty: | 5-year |
| Firmware support to: | 5 year after EOL |
| Protocols supported: | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP (TCP, UDP Unicast) |
| Security: | OS / Firmware Protect: Secure boot, Signed firmware, Firmware encryption
User authentication: Digest Authentication, Prevent brute-force attack Network authentication: 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Secure Communication: HTTPS, SRTP, WSS(Websocket secure) Access Control: Access control based on IP address Data Protect: Authentication information encryption, ZIP compression encryption Audit: User Access/System/Event log management Device ID: Device Certificate(Hanwha Private Root CA) |
